Airport Ground Support parts lists

BOMwiki maps 21 airport ground support products, each exploded into a recursive bill of materials: 1,868 parts in total, down to individual fasteners and cells. The largest is the airport pushback tractor at 250 parts across 11 top-level assemblies; the simplest is the ground power unit at 33. Across the domain the same components recur: alloy wheel, lug nut, tire and TPMS sensor appear in most of these machines, and each is a single shared page here, so a correction to one fixes every product that uses it. Open any product for its parts diagram, the function of each part, and the full bill of materials.

21 airport ground support products

Air Start Unit Portable gas-turbine or piston compressor delivering 280–400 °C pressurized bleed air to aircraft engines for cold-start ignition and rotation. 33 parts · 8 subsystems

Aircraft Belt Loader A ground support vehicle with an inclined conveyor belt and hydraulic lift, transporting baggage and cargo between aircraft and ground trucks. 87 parts · 8 subsystems

Aircraft De-Icing Rig Heated glycol spray system mounted on a boom, combining heated tanks, nozzle arrays, and blend proportioning for aircraft anti-ice and de-icing treatment. 113 parts · 8 subsystems

Aircraft De-Icing Truck A specialized airport vehicle with heated fluid tanks, pressurized boom with spray nozzle, and proportioning system for applying de-icing fluid to aircraft surfaces. 100 parts · 8 subsystems

Aircraft GPU (Ground Power Unit) 400 Hz AC power generator on trailer providing 90–180 kVA to aircraft during ground operations, eliminating aux power unit fuel burn and noise. 38 parts · 8 subsystems

Aircraft Lavatory Service Truck A specialized airport service vehicle with waste tank, flush water tank, and transfer pumps for servicing aircraft lavatories. 82 parts · 8 subsystems

Aircraft Pushback Tug Heavy ballasted towbarless tug with hydraulic lift cradle or towbar hitch, low-profile cab, and multi-speed diesel drivetrain for aircraft apron maneuvering. 93 parts · 9 subsystems

Airport Catering Truck A specialized truck with an elevating scissor-lift box body, refrigeration system, and stabilizer feet for loading meal service carts into aircraft cabins. 115 parts · 9 subsystems

Airport Pushback Tractor A low, heavily ballasted ground-support tractor that pushes parked aircraft back from the gate, coupling to the nose gear through a towbar or a towbarless cradle. 250 parts · 11 subsystems

Airport Refueling Truck A specialized heavy truck with an internal fuel tank and bottom-loading/bottom-unloading pump system, metering and filtering fuel to parked aircraft via a breakaway coupling. 128 parts · 8 subsystems

Baggage Tractor Compact tug with electric or diesel drivetrain, tow hitch, and low-profile design for hauling baggage trains (3–5 dollies) at airport terminals. 74 parts · 8 subsystems

Baggage Tug A small ground-support tractor designed to tow baggage carts and other ground equipment on airport aprons, powered by electric or diesel drive. 47 parts · 8 subsystems

Belt Loader Self-propelled belt conveyor elevating baggage/cargo from ground to aircraft cargo door height, with motorized belt and articulated boom. 93 parts · 7 subsystems

Catering Hi-Loft Truck Scissor-lift van body elevating food/beverage carts to aircraft cabin door height, with transfer bridge and multi-deck galley cart interface. 82 parts · 8 subsystems

Conventional Tow Tractor Ballasted tractor with towbar coupling for aircraft nose gear linkage, enabling towing at 5–25 km/h on apron and taxi routes. 96 parts · 8 subsystems

Ground Power Unit Diesel generator or solid-state converter delivering 400 Hz 115/208 V AC power to parked aircraft, with cable reel and distribution panel. 33 parts · 8 subsystems

Jet Bridge A wheeled boarding tunnel that extends and rotates to an aircraft door, carrying passengers from the terminal building to the cabin entrance. 62 parts · 8 subsystems

Lavatory Service Truck Mobile waste/fresh water service vehicle with vacuum pump, transfer tanks, and hose cabinet for aircraft lavatory servicing. 73 parts · 8 subsystems

Passenger Boarding Stairs A mobile elevated stairway that positions its flight of steps at an aircraft cabin door, allowing self-boarding when a jet bridge is unavailable. 104 parts · 8 subsystems

Potable Water Service Truck Specialized tanker truck delivering sanitary drinking water to aircraft, with heated tank, pressure pump, hose reel, and water quality monitoring. 77 parts · 9 subsystems

Runway Sweeper Blower An airport ground-support vehicle with a rotating broom cassette and high-velocity blower that sweeps and clears snow, water, and debris from runways and taxiways. 88 parts · 7 subsystems

Parts common across airport ground support 11

Shared components ranked by how many of the 21 products in this domain contain them, directly or inside a sub-assembly.

Alloy Wheel in 15 of 21 productsCast or forged aluminium-alloy wheel that mounts the tyre and bolts to the hub, lighter than a steel wheel of the same size.
Lug Nut in 15 of 21 productsTapered nut that clamps the wheel to the hub studs, tightened to a specified torque in a star pattern.
Tire in 15 of 21 productsPneumatic rubber tyre mounted on a wheel rim that carries the vehicle load, grips the ground, and cushions the ride.
TPMS Sensor in 15 of 21 productsBattery-powered sensor inside the wheel that measures tyre pressure and temperature and radios the readings to the vehicle.
Valve Stem in 15 of 21 productsRubber or metal valve through the wheel rim that lets the tyre be inflated and holds the pressure with a spring-loaded core.
Wheel Assembly in 15 of 21 productsComplete road wheel: rim, tyre, valve, pressure sensor, and fasteners, balanced and ready to bolt onto the hub.
Pressure Sensor in 5 of 21 productsTransduces fluid or gas pressure into an electrical signal.
Fastener Set in 4 of 21 productsBolts, nuts, and washers.
12 V Battery in 3 of 21 products12 V lead-acid or lithium battery that powers the vehicle's low-voltage electronics and starts or wakes the main system.
LCD Panel in 3 of 21 productsLiquid-crystal display module with backlight and driver electronics that shows the machine's readouts, menus, and status to the operator.
Wire Bundle in 3 of 21 productsGroup of insulated conductors cut to length, terminated, and bound together to carry power and signals between the assemblies of a machine.
