Floor Scrubber Product
Walk-behind automatic floor scrubber: a self-propelled chassis carries solution and recovery tanks, a rotary scrub deck wets and agitates the floor, and a squeegee plus vacuum motor reclaim the dirty water into the recovery tank. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
11 top-level lines · 85 rows shown · 279 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Chassis & Housing 4 parts | floor-scrubber-chassis | 1× | 1 | 6 | assembly |
| 1.1 | Steel Frame Weldment | floor-scrubber-frame | 1× | 1 | — | part |
| 1.2 | Body Panel | floor-scrubber-body-panel | 3× | 3 | — | part |
| 1.3 | Wrap-Around Bumper | floor-scrubber-bumper | 1× | 1 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Solution Tank 3 parts | floor-scrubber-solution-tank | 1× | 1 | 3 | assembly |
| 2.1 | Solution Tank Shell | floor-scrubber-solution-shell | 1× | 1 | — | part |
| 2.2 | Tank Lid | floor-scrubber-tank-lid | 1× | 1 | — | part |
| 2.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3 | Recovery Tank 5 parts | floor-scrubber-recovery-tank | 1× | 1 | 5 | assembly |
| 3.1 | Recovery Tank Shell | floor-scrubber-recovery-shell | 1× | 1 | — | part |
| 3.2 | Tank Lid | floor-scrubber-tank-lid | 1× | 1 | — | part |
| 3.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3.4 | Float Shutoff | floor-scrubber-float-shutoff | 1× | 1 | — | part |
| 3.5 | Drain Hose | floor-scrubber-drain-hose | 1× | 1 | — | part |
| 4 | Scrub Deck 5 parts | floor-scrubber-scrub-deck | 1× | 1 | 65 | assembly |
| 4.1 | Deck Housing | floor-scrubber-deck-housing | 1× | 1 | — | part |
| 4.2 | Rotary Brush/Pad Disc | floor-scrubber-brush-disc | 2× | 2 | — | part |
| 4.3 | Brush Drive Motor 5 parts | floor-scrubber-brush-motor | 2× | 2 | 26 | assembly |
| 4.3.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 2 | 3 | assembly |
| 4.3.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 2 | 19 | assembly |
| 4.3.3 | Copper Winding | copper-winding | 1× | 2 | — | part |
| 4.3.4 | Motor Housing | motor-housing | 1× | 2 | — | part |
| 4.3.5 | Ball Bearing | ball-bearing | 2× | 4 | — | part |
| 4.4 | Deck Gearbox 3 parts | floor-scrubber-deck-gearbox | 2× | 2 | 4 | assembly |
| 4.4.1 | Helical Gear Pair | gear-pair | 1× | 2 | — | part |
| 4.4.2 | Ball Bearing | ball-bearing | 2× | 4 | — | part |
| 4.4.3 | O-Ring Set | oring-set | 1× | 2 | — | part |
| 4.5 | Deck Lift Actuator 2 parts | floor-scrubber-deck-lift | 1× | 1 | 2 | assembly |
| 4.5.1 | Lift Actuator Motor | floor-scrubber-lift-motor | 1× | 1 | — | part |
| 4.5.2 | Lift Lead Screw | floor-scrubber-lift-screw | 1× | 1 | — | part |
| 5 | Vacuum & Squeegee System 3 parts | floor-scrubber-vacuum-system | 1× | 1 | 30 | assembly |
| 5.1 | Vacuum Motor 5 parts | floor-scrubber-vacuum-motor | 1× | 1 | 26 | assembly |
| 5.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 5.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 5.1.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 5.1.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 5.1.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 5.2 | Squeegee Assembly 2 parts | floor-scrubber-squeegee-assembly | 1× | 1 | 3 | assembly |
| 5.2.1 | Squeegee Blade | floor-scrubber-squeegee-blade | 2× | 2 | — | part |
| 5.2.2 | Squeegee Frame | floor-scrubber-squeegee-frame | 1× | 1 | — | part |
| 5.3 | Recovery Hose | floor-scrubber-recovery-hose | 1× | 1 | — | part |
| 6 | Solution Delivery System 3 parts | floor-scrubber-solution-system | 1× | 1 | 3 | assembly |
| 6.1 | Solution Pump | floor-scrubber-solution-pump | 1× | 1 | — | part |
| 6.2 | Solution Valve | floor-scrubber-solution-valve | 1× | 1 | — | part |
| 6.3 | Flow Control | floor-scrubber-flow-control | 1× | 1 | — | part |
| 7 | Traction Drive 4 parts | floor-scrubber-traction-drive | 1× | 1 | 33 | assembly |
| 7.1 | Drive Wheel | floor-scrubber-drive-wheel | 1× | 1 | — | part |
| 7.2 | Traction Motor 5 parts | floor-scrubber-drive-motor | 1× | 1 | 26 | assembly |
| 7.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 7.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 7.2.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 7.2.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 7.2.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 7.3 | Drive Transaxle 3 parts | floor-scrubber-drive-transaxle | 1× | 1 | 4 | assembly |
| 7.3.1 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 7.3.2 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 7.3.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 7.4 | Support Caster | floor-scrubber-caster | 2× | 2 | — | part |
| 8 | Battery Pack 5 parts | floor-scrubber-battery-pack | 1× | 1 | 93 | assembly |
| 8.1 | Li-ion Cell, 18650 | li-cell-18650 | 80× | 80 | — | part |
| 8.2 | 12 V Battery | lv-battery | 1× | 1 | — | part |
| 8.3 | BMS Board | bms-board | 1× | 1 | — | part |
| 8.4 | Onboard Charger 3 parts | floor-scrubber-charger | 1× | 1 | 9 | assembly |
| 8.4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.4.2 | Power MOSFET | mosfet | 6× | 6 | — | part |
| 8.4.3 | Power Inductor | power-inductor | 2× | 2 | — | part |
| 8.5 | Connector | connector | 2× | 2 | — | part |
| 9 | Control Board 6 parts | floor-scrubber-control-board | 1× | 1 | 22 | assembly |
| 9.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 9.3 | Relay | relay | 6× | 6 | — | part |
| 9.4 | Power MOSFET | mosfet | 8× | 8 | — | part |
| 9.5 | Control Panel 2 parts | floor-scrubber-control-panel | 1× | 1 | 2 | assembly |
| 9.5.1 | Membrane Keypad | floor-scrubber-membrane-keypad | 1× | 1 | — | part |
| 9.5.2 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.6 | Connector | connector | 4× | 4 | — | part |
| 10 | Handle & Controls 3 parts | floor-scrubber-handle-console | 1× | 1 | 4 | assembly |
| 10.1 | Handle Bar | floor-scrubber-handle-bar | 1× | 1 | — | part |
| 10.2 | Drive Control Lever | floor-scrubber-control-lever | 2× | 2 | — | part |
| 10.3 | Throttle Potentiometer | floor-scrubber-throttle-pot | 1× | 1 | — | part |
| 11 | Machine Wiring Harness 3 parts | floor-scrubber-wiring | 1× | 1 | 15 | assembly |
| 11.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 11.2 | Connector | connector | 12× | 12 | — | part |
| 11.3 | Relay | relay | 2× | 2 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $50–$1.5k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| sharkninja.com ↗ | Needham, US | Floorcare & kitchen | 1,000 units | 8–12 wks |
| 🇬🇧Dyson dyson.com ↗ | Malmesbury, GB | Vacuums & hair care | 1,000 units | 8–12 wks |
| 🇺🇸Bissell bissell.com ↗ | Grand Rapids, US | Floorcare | 1,000 units | 8–12 wks |
| 🇺🇸iRobot irobot.com ↗ | Bedford, US | Robot vacuums | 1,000 units | 8–12 wks |
| 🇩🇪Kärcher karcher.com ↗ | Winnenden, DE | Cleaning equipment | 1,000 units | 8–12 wks |
