Wet/Dry Shop Vacuum Product
A portable wet/dry shop vacuum: a plastic drum on a caster dolly, a bypass vacuum motor with an impeller blower in the lid, cartridge/foam filtration with a float shutoff for wet pickup, and a hose/wand/nozzle set with a blower port and on-board accessory storage. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
6 top-level lines · 36 rows shown · 55 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Drum & Dolly Assembly 8 parts | wet-dry-vacuum-drum-assembly | 1× | 1 | 12 | assembly |
| 1.1 | Polyethylene Tank | wet-dry-vacuum-tank | 1× | 1 | — | part |
| 1.2 | Power-Head Lid | wet-dry-vacuum-lid | 1× | 1 | — | part |
| 1.3 | Lid Latch | wet-dry-vacuum-latch | 2× | 2 | — | part |
| 1.4 | Caster Dolly Base | wet-dry-vacuum-dolly-base | 1× | 1 | — | part |
| 1.5 | Swivel Caster | wet-dry-vacuum-caster | 4× | 4 | — | part |
| 1.6 | Drain Plug | wet-dry-vacuum-drain-plug | 1× | 1 | — | part |
| 1.7 | Suction Inlet Port | wet-dry-vacuum-inlet-port | 1× | 1 | — | part |
| 1.8 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 2 | Motor & Blower Power Head 5 parts | wet-dry-vacuum-power-head | 1× | 1 | 30 | assembly |
| 2.1 | Bypass Vacuum Motor 5 parts | wet-dry-vacuum-bypass-motor | 1× | 1 | 26 | assembly |
| 2.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.1.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.1.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 2.1.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.2 | Suction Impeller | wet-dry-vacuum-impeller | 1× | 1 | — | part |
| 2.3 | Motor Cooling Fan | wet-dry-vacuum-cooling-fan | 1× | 1 | — | part |
| 2.4 | Blower Exhaust Port | wet-dry-vacuum-blower-port | 1× | 1 | — | part |
| 2.5 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3 | Filtration Set 4 parts | wet-dry-vacuum-filtration-set | 1× | 1 | 4 | assembly |
| 3.1 | Cartridge Filter | wet-dry-vacuum-cartridge-filter | 1× | 1 | — | part |
| 3.2 | Foam Filter Sleeve | wet-dry-vacuum-foam-filter | 1× | 1 | — | part |
| 3.3 | Filter Cage | wet-dry-vacuum-filter-cage | 1× | 1 | — | part |
| 3.4 | Float Shutoff | wet-dry-vacuum-float-shutoff | 1× | 1 | — | part |
| 4 | Hose & Accessory Kit 4 parts | wet-dry-vacuum-hose-kit | 1× | 1 | 4 | assembly |
| 4.1 | Suction Hose | wet-dry-vacuum-hose | 1× | 1 | — | part |
| 4.2 | Extension Wand | wet-dry-vacuum-wand | 1× | 1 | — | part |
| 4.3 | Floor Nozzle | wet-dry-vacuum-floor-nozzle | 1× | 1 | — | part |
| 4.4 | Accessory Caddy | wet-dry-vacuum-accessory-caddy | 1× | 1 | — | part |
| 5 | Electrical Set 4 parts | wet-dry-vacuum-electrical-set | 1× | 1 | 4 | assembly |
| 5.1 | Power Switch | wet-dry-vacuum-power-switch | 1× | 1 | — | part |
| 5.2 | Power Cord | wet-dry-vacuum-cord | 1× | 1 | — | part |
| 5.3 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 5.4 | Connector | connector | 1× | 1 | — | part |
| 6 | Fastener Set | fastener-set | 1× | 1 | — | part |
