Leaf Blower Product
A cordless handheld leaf blower: a brushless motor spins an axial impeller, accelerating intake air through a volute and out a nozzle to clear leaves and debris. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
8 top-level lines · 45 rows shown · 68 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Power Unit 4 parts | leaf-blower-power-unit | 1× | 1 | 30 | assembly |
| 1.1 | BLDC Motor 4 parts | leaf-blower-motor | 1× | 1 | 24 | assembly |
| 1.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 1.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 1.1.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 1.1.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 1.2 | Motor Controller 3 parts | leaf-blower-controller | 1× | 1 | 3 | assembly |
| 1.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.2.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 1.2.3 | Power MOSFET Stage | leaf-blower-power-mosfets | 1× | 1 | — | part |
| 1.3 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Battery Pack 4 parts | leaf-blower-battery-pack | 1× | 1 | 13 | assembly |
| 2.1 | Li-ion Cell, 18650 | li-cell-18650 | 10× | 10 | — | part |
| 2.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 2.3 | Battery Housing | leaf-blower-battery-housing | 1× | 1 | — | part |
| 2.4 | Connector | connector | 1× | 1 | — | part |
| 3 | Impeller Assembly 5 parts | leaf-blower-impeller-assembly | 1× | 1 | 5 | assembly |
| 3.1 | Impeller (Fan) | leaf-blower-fan | 1× | 1 | — | part |
| 3.2 | Volute Housing | leaf-blower-volute | 1× | 1 | — | part |
| 3.3 | Impeller Retaining Nut | leaf-blower-fan-nut | 1× | 1 | — | part |
| 3.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 3.5 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 4 | Intake Assembly 3 parts | leaf-blower-intake-assembly | 1× | 1 | 3 | assembly |
| 4.1 | Intake Grille | leaf-blower-intake-grille | 1× | 1 | — | part |
| 4.2 | Intake Filter | leaf-blower-intake-filter | 1× | 1 | — | part |
| 4.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 5 | Blower Tube Assembly 4 parts | leaf-blower-tube-assembly | 1× | 1 | 4 | assembly |
| 5.1 | Blower Tube | leaf-blower-tube | 1× | 1 | — | part |
| 5.2 | Nozzle | leaf-blower-nozzle | 1× | 1 | — | part |
| 5.3 | Flat Concentrator | leaf-blower-concentrator | 1× | 1 | — | part |
| 5.4 | Tube Latch | leaf-blower-tube-latch | 1× | 1 | — | part |
| 6 | Handle Assembly 4 parts | leaf-blower-handle-assembly | 1× | 1 | 4 | assembly |
| 6.1 | Handle Grip | leaf-blower-grip | 1× | 1 | — | part |
| 6.2 | Throttle Trigger | leaf-blower-throttle-trigger | 1× | 1 | — | part |
| 6.3 | Cruise Control Dial | leaf-blower-cruise-control | 1× | 1 | — | part |
| 6.4 | Connector | connector | 1× | 1 | — | part |
| 7 | Housing 4 parts | leaf-blower-housing | 1× | 1 | 5 | assembly |
| 7.1 | Housing Shell | leaf-blower-housing-shell | 2× | 2 | — | part |
| 7.2 | Anti-Vibration Mount Set | leaf-blower-av-mounts | 1× | 1 | — | part |
| 7.3 | Battery Mount | leaf-blower-battery-mount | 1× | 1 | — | part |
| 7.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 8 | Internal Wiring 2 parts | leaf-blower-wiring | 1× | 1 | 4 | assembly |
| 8.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 8.2 | Connector | connector | 3× | 3 | — | part |
