LED High Bay Light Product
A 150-watt UFO-style round LED high bay luminaire for warehouse and factory ceilings, hung from a mounting hook with an integrated isolated driver. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
11 top-level lines · 40 rows shown · 153 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Finned Heat Sink Body 3 parts | high-bay-light-heat-sink | 1× | 1 | 3 | assembly |
| 1.1 | Die-Cast Finned Casting | high-bay-light-heat-sink-casting | 1× | 1 | — | part |
| 1.2 | Thermal Interface Pad | high-bay-light-thermal-pad | 1× | 1 | — | part |
| 1.3 | Hanging Boss | high-bay-light-mount-boss | 1× | 1 | — | part |
| 2 | LED Board (MCPCB) 4 parts | high-bay-light-led-board | 1× | 1 | 123 | assembly |
| 2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.2 | White LED Package | high-bay-light-led-package | 120× | 120 | — | part |
| 2.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 2.4 | Solder Paste | high-bay-light-solder-paste | 1× | 1 | — | part |
| 3 | Aluminium Reflector | high-bay-light-reflector | 1× | 1 | — | part |
| 4 | PC Diffuser Cover 3 parts | high-bay-light-cover | 1× | 1 | 3 | assembly |
| 4.1 | Polycarbonate Diffuser Lens | high-bay-light-diffuser-lens | 1× | 1 | — | part |
| 4.2 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 4.3 | Retaining Ring | high-bay-light-retaining-ring | 1× | 1 | — | part |
| 5 | LED Driver Module 8 parts | high-bay-light-driver | 1× | 1 | 9 | assembly |
| 5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 5.3 | Bridge Rectifier | high-bay-light-bridge-rectifier | 1× | 1 | — | part |
| 5.4 | Isolation Transformer | high-bay-light-transformer | 1× | 1 | — | part |
| 5.5 | Electrolytic Capacitor | high-bay-light-electrolytic-cap | 2× | 2 | — | part |
| 5.6 | LED Driver IC | high-bay-light-driver-ic | 1× | 1 | — | part |
| 5.7 | Mains Terminal Block | high-bay-light-terminal-block | 1× | 1 | — | part |
| 5.8 | Potted Driver Can | high-bay-light-driver-can | 1× | 1 | — | part |
| 6 | Mounting Bracket & Hook 3 parts | high-bay-light-mount | 1× | 1 | 3 | assembly |
| 6.1 | Mounting Hook | high-bay-light-hook | 1× | 1 | — | part |
| 6.2 | Safety Chain | high-bay-light-safety-chain | 1× | 1 | — | part |
| 6.3 | Stirrup Bracket | high-bay-light-bracket | 1× | 1 | — | part |
| 7 | Motion/Daylight Sensor 5 parts | high-bay-light-sensor | 1× | 1 | 5 | assembly |
| 7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 7.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 7.4 | PIR Sensor Element | high-bay-light-pir-sensor | 1× | 1 | — | part |
| 7.5 | Fresnel Lens | high-bay-light-lens-fresnel | 1× | 1 | — | part |
| 8 | Power Cord 3 parts | high-bay-light-cord | 1× | 1 | 3 | assembly |
| 8.1 | Mains Cable | high-bay-light-cable | 1× | 1 | — | part |
| 8.2 | Connector | connector | 1× | 1 | — | part |
| 8.3 | Cable Gland | high-bay-light-strain-relief | 1× | 1 | — | part |
| 9 | Surge Protector | high-bay-light-surge-protector | 1× | 1 | — | part |
| 10 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 11 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
