Track Light System Product

A 3-circuit ceiling track lighting system: an extruded aluminium rail with copper busbars feeding three adjustable LED spotlight heads. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

4 top-level lines · 40 rows shown · 95 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Track Rail 8 parts track-light-rail 1× 1 15 assembly
1.1 Aluminium Track Extrusion track-light-extrusion 1× 1 — part
1.2 Copper Busbar track-light-busbar 4× 4 — part
1.3 Busbar Insulator Carrier track-light-busbar-insulator 1× 1 — part
1.4 Track End Cap track-light-end-cap 2× 2 — part
1.5 Mounting Clip track-light-mounting-clip 4× 4 — part
1.6 Power Feed Connector track-light-power-feed 1× 1 — part
1.7 Track Joiner track-light-joiner 1× 1 — part
1.8 Connector connector 1× 1 — part
2 Spotlight Head 10 parts track-light-head 3× 3 26 assembly
2.1 Track Adapter 4 parts track-light-adapter 1× 3 7 assembly
2.1.1 Adapter Body track-light-adapter-body 1× 3 — part
2.1.2 Sprung Contact Pin track-light-contact-pin 4× 12 — part
2.1.3 Locking Lever track-light-locking-lever 1× 3 — part
2.1.4 Ball Bearing ball-bearing 1× 3 — part
2.2 Gimbal Joint 3 parts track-light-gimbal-joint 1× 3 3 assembly
2.2.1 Mounting Yoke track-light-yoke 1× 3 — part
2.2.2 Ball Bearing ball-bearing 1× 3 — part
2.2.3 Fastener Set fastener-set 1× 3 — part
2.3 Pivot Joint 3 parts track-light-pivot-joint 1× 3 3 assembly
2.3.1 Ball Bearing ball-bearing 1× 3 — part
2.3.2 Friction Washer track-light-friction-washer 1× 3 — part
2.3.3 Fastener Set fastener-set 1× 3 — part
2.4 COB LED Module 4 parts track-light-cob-module 1× 3 4 assembly
2.4.1 Bare PCB pcb-bare 1× 3 — part
2.4.2 SMD Passive (R/C/L) smd-passives 1× 3 — part
2.4.3 COB LED Emitter track-light-cob-emitter 1× 3 — part
2.4.4 Connector connector 1× 3 — part
2.5 LED Driver 4 parts track-light-driver 1× 3 4 assembly
2.5.1 Bare PCB pcb-bare 1× 3 — part
2.5.2 SMD Passive (R/C/L) smd-passives 1× 3 — part
2.5.3 Constant-Current Driver IC track-light-driver-ic 1× 3 — part
2.5.4 Connector connector 1× 3 — part
2.6 Reflector track-light-reflector 1× 3 — part
2.7 Beam Lens track-light-lens 1× 3 — part
2.8 Heat Sink track-light-heat-sink 1× 3 — part
2.9 Decorative Housing track-light-housing 1× 3 — part
2.10 Wire Bundle wire-bundle 1× 3 — part
3 Wire Bundle wire-bundle 1× 1 — part
4 Fastener Set fastener-set 1× 1 — part
