Smart Bulb Product
A Wi-Fi/BLE RGBW smart bulb with an E27 Edison base, app and voice control, and tunable colour and white light. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 22 rows shown · 27 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Edison Base (E27) 3 parts | smart-bulb-edison-base | 1× | 1 | 3 | assembly |
| 1.1 | E27 Screw Cap | smart-bulb-e27-cap | 1× | 1 | — | part |
| 1.2 | Eyelet Contact | smart-bulb-eyelet-contact | 1× | 1 | — | part |
| 1.3 | Base Insulator | smart-bulb-base-insulator | 1× | 1 | — | part |
| 2 | Driver & Control Board 7 parts | smart-bulb-control-board | 1× | 1 | 10 | assembly |
| 2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 2.3 | AC-DC Driver Module | smart-bulb-acdc-driver | 1× | 1 | — | part |
| 2.4 | Wi-Fi/BLE SoC Module | smart-bulb-wifi-soc | 1× | 1 | — | part |
| 2.5 | PCB/Chip Antenna | smart-bulb-antenna | 1× | 1 | — | part |
| 2.6 | Microcontroller | mcu | 1× | 1 | — | part |
| 2.7 | LED Driver IC | smart-bulb-led-driver-ic | 4× | 4 | — | part |
| 3 | LED Board (MCPCB) 5 parts | smart-bulb-led-board | 1× | 1 | 10 | assembly |
| 3.1 | Aluminium MCPCB Substrate | smart-bulb-mcpcb | 1× | 1 | — | part |
| 3.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.3 | RGB LED Package | smart-bulb-rgb-led | 3× | 3 | — | part |
| 3.4 | White LED Package | smart-bulb-white-led | 4× | 4 | — | part |
| 3.5 | Solder Paste | smart-bulb-solder-paste | 1× | 1 | — | part |
| 4 | Heat Sink Body | smart-bulb-heat-sink | 1× | 1 | — | part |
| 5 | Diffuser Dome | smart-bulb-diffuser | 1× | 1 | — | part |
| 6 | Thermal Interface Pad | smart-bulb-thermal-pad | 1× | 1 | — | part |
| 7 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
