LED Panel Light Product
A 600x600 mm edge-lit LED panel: an anodised aluminium frame holds a PMMA light guide plate edge-injected by MCPCB LED strips, with a reflector behind and a diffuser in front, closed by a back plate; an external constant-current LED driver powers it through a quick-connect lead. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
11 top-level lines · 32 rows shown · 327 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Aluminium Frame 3 parts | led-panel-light-frame | 1× | 1 | 9 | assembly |
| 1.1 | Frame Extrusion | led-panel-light-frame-extrusion | 4× | 4 | — | part |
| 1.2 | Corner Bracket | led-panel-light-corner-bracket | 4× | 4 | — | part |
| 1.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | LED Edge Strip 5 parts | led-panel-light-edge-strip | 4× | 4 | 74 | assembly |
| 2.1 | Bare PCB | pcb-bare | 1× | 4 | — | part |
| 2.2 | LED Chip | led-panel-light-led-chip | 70× | 280 | — | part |
| 2.3 | SMD Passive (R/C/L) | smd-passives | 1× | 4 | — | part |
| 2.4 | Connector | connector | 1× | 4 | — | part |
| 2.5 | Thermal Interface Tape | led-panel-light-thermal-tape | 1× | 4 | — | part |
| 3 | Light Guide Plate | led-panel-light-lgp | 1× | 1 | — | part |
| 4 | Diffuser Sheet | led-panel-light-diffuser | 1× | 1 | — | part |
| 5 | Reflector Sheet | led-panel-light-reflector | 1× | 1 | — | part |
| 6 | Back Plate | led-panel-light-back-plate | 1× | 1 | — | part |
| 7 | Front Lens | led-panel-light-front-lens | 1× | 1 | — | part |
| 8 | LED Driver 6 parts | led-panel-light-driver | 1× | 1 | 7 | assembly |
| 8.1 | Driver Housing | led-panel-light-driver-housing | 1× | 1 | — | part |
| 8.2 | Driver Board 2 parts | led-panel-light-driver-board | 1× | 1 | 2 | assembly |
| 8.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.2.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 8.3 | Bridge Rectifier | led-panel-light-rectifier | 1× | 1 | — | part |
| 8.4 | Switching Transformer | led-panel-light-transformer | 1× | 1 | — | part |
| 8.5 | Connector | connector | 1× | 1 | — | part |
| 8.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 9 | Input Lead 2 parts | led-panel-light-input-lead | 1× | 1 | 2 | assembly |
| 9.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 9.2 | Connector | connector | 1× | 1 | — | part |
| 10 | Mounting Kit 3 parts | led-panel-light-mount-kit | 1× | 1 | 7 | assembly |
| 10.1 | Mounting Clip | led-panel-light-mount-clip | 4× | 4 | — | part |
| 10.2 | Mounting Bracket | led-panel-light-mount-bracket | 2× | 2 | — | part |
| 10.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 11 | Fastener Set | fastener-set | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $3–$2k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| 🇳🇱Signify signify.com ↗ | Eindhoven, NL | Lighting (Philips Hue) | 2,000 units | 6–10 wks |
| acuitybrands.com ↗ | Atlanta, US | Lighting & controls | 2,000 units | 6–10 wks |
| 🇦🇹Zumtobel zumtobelgroup.com ↗ | Dornbirn, AT | Lighting | 2,000 units | 6–10 wks |
| creelighting.com ↗ | Racine, US | LED lighting | 2,000 units | 6–10 wks |
| 🇮🇳Havells havells.com ↗ | Noida, IN | Electrical & lighting | 2,000 units | 6–10 wks |
