Moving Head Stage Light Product
A motorized beam/spot moving-head fixture with an LED engine, color and gobo optics on a pan/tilt yoke. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
6 top-level lines · 77 rows shown · 478 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Base Assembly 6 parts | stage-moving-head-base | 1× | 1 | 295 | assembly |
| 1.1 | Base Housing | stage-moving-head-base-housing | 1× | 1 | — | part |
| 1.2 | Omega Rigging Bracket | stage-moving-head-omega-bracket | 2× | 2 | — | part |
| 1.3 | Display & Keypad 5 parts | stage-moving-head-display | 1× | 1 | 38 | assembly |
| 1.3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.3.2 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 1.3.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 1.3.4 | Menu Button / Encoder | stage-moving-head-button | 5× | 5 | — | part |
| 1.3.5 | SMD Passive (R/C/L) | smd-passives | 30× | 30 | — | part |
| 1.4 | Main Control Board 7 parts | stage-moving-head-control-board | 1× | 1 | 246 | assembly |
| 1.4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.4.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 1.4.3 | Microcontroller | mcu | 2× | 2 | — | part |
| 1.4.4 | RS-485 Transceiver | stage-moving-head-dmx-transceiver | 2× | 2 | — | part |
| 1.4.5 | Stepper Driver IC | stage-moving-head-motor-driver | 8× | 8 | — | part |
| 1.4.6 | Connector | connector | 12× | 12 | — | part |
| 1.4.7 | SMD Passive (R/C/L) | smd-passives | 220× | 220 | — | part |
| 1.5 | I/O Panel 3 parts | stage-moving-head-io-panel | 1× | 1 | 6 | assembly |
| 1.5.1 | DMX XLR Connector | stage-moving-head-dmx-connector | 2× | 2 | — | part |
| 1.5.2 | Connector | connector | 2× | 2 | — | part |
| 1.5.3 | Connector | connector | 2× | 2 | — | part |
| 1.6 | Cooling Fan | stage-moving-head-fan | 2× | 2 | — | part |
| 2 | Yoke & Pan/Tilt 3 parts | stage-moving-head-yoke | 1× | 1 | 58 | assembly |
| 2.1 | Yoke Arm | stage-moving-head-yoke-arm | 2× | 2 | — | part |
| 2.2 | Pan Drive 7 parts | stage-moving-head-pan-drive | 1× | 1 | 28 | assembly |
| 2.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 2.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.2.3 | Drive Belt | drive-belt | 1× | 1 | — | part |
| 2.2.4 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 2.2.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.2.6 | Position Encoder | stage-moving-head-position-encoder | 1× | 1 | — | part |
| 2.2.7 | Hall Home Sensor | stage-moving-head-hall-sensor | 1× | 1 | — | part |
| 2.3 | Tilt Drive 7 parts | stage-moving-head-tilt-drive | 1× | 1 | 28 | assembly |
| 2.3.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 2.3.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.3.3 | Drive Belt | drive-belt | 1× | 1 | — | part |
| 2.3.4 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 2.3.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.3.6 | Position Encoder | stage-moving-head-position-encoder | 1× | 1 | — | part |
| 2.3.7 | Hall Home Sensor | stage-moving-head-hall-sensor | 1× | 1 | — | part |
| 3 | Optical Head 12 parts | stage-moving-head-head | 1× | 1 | 119 | assembly |
| 3.1 | Head Housing | stage-moving-head-head-housing | 1× | 1 | — | part |
| 3.2 | LED Light Engine 2 parts | stage-moving-head-led-engine | 1× | 1 | 69 | assembly |
| 3.2.1 | LED Array Module | stage-moving-head-led-array | 1× | 1 | — | part |
| 3.2.2 | LED Driver Board 5 parts + deeper › | stage-moving-head-led-driver | 1× | 1 | 68 | assembly |
| 3.3 | Reflector | stage-moving-head-reflector | 1× | 1 | — | part |
| 3.4 | Zoom Lens Group 2 parts | stage-moving-head-zoom-group | 1× | 1 | 3 | assembly |
| 3.4.1 | Optical Lens | stage-moving-head-lens | 2× | 2 | — | part |
| 3.4.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 1 | — | part |
| 3.5 | Focus Lens Group 2 parts | stage-moving-head-focus-group | 1× | 1 | 2 | assembly |
| 3.5.1 | Optical Lens | stage-moving-head-lens | 1× | 1 | — | part |
| 3.5.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 1 | — | part |
| 3.6 | Color Wheel 2 parts | stage-moving-head-color-wheel | 1× | 1 | 2 | assembly |
| 3.6.1 | Dichroic Color Disc | stage-moving-head-color-disc | 1× | 1 | — | part |
| 3.6.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 1 | — | part |
| 3.7 | Gobo Wheel 3 parts | stage-moving-head-gobo-wheel | 2× | 2 | 9 | assembly |
| 3.7.1 | Gobo | stage-moving-head-gobo | 7× | 14 | — | part |
| 3.7.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 2 | — | part |
| 3.7.3 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 2 | — | part |
| 3.8 | Prism Effect 2 parts | stage-moving-head-prism | 1× | 1 | 3 | assembly |
| 3.8.1 | Prism Element | stage-moving-head-prism-element | 1× | 1 | — | part |
| 3.8.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 2× | 2 | — | part |
| 3.9 | Iris 2 parts | stage-moving-head-iris | 1× | 1 | 13 | assembly |
| 3.9.1 | Iris Blade | stage-moving-head-iris-blade | 12× | 12 | — | part |
| 3.9.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 1 | — | part |
| 3.10 | Frost Filter 2 parts | stage-moving-head-frost | 1× | 1 | 2 | assembly |
| 3.10.1 | Optical Lens | stage-moving-head-lens | 1× | 1 | — | part |
| 3.10.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 1× | 1 | — | part |
| 3.11 | Shutter / Dimmer 2 parts | stage-moving-head-shutter | 1× | 1 | 4 | assembly |
| 3.11.1 | Shutter Blade | stage-moving-head-shutter-blade | 2× | 2 | — | part |
| 3.11.2 | Effect Stepper Motor | stage-moving-head-effect-motor | 2× | 2 | — | part |
| 3.12 | Cooling Fan | stage-moving-head-fan | 1× | 1 | — | part |
| 4 | Power Supply 2 parts | stage-moving-head-power-supply | 1× | 1 | 4 | assembly |
| 4.1 | Power Supply | power-supply | 1× | 1 | — | part |
| 4.2 | Connector | connector | 3× | 3 | — | part |
| 5 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6 | Fastener Set | fastener-set | 1× | 1 | — | part |
