LED Neon Sign Product
A custom LED flex-neon sign: silicone neon-flex tubes bent to a logo and mounted on a cut acrylic backing board, run from a low-voltage driver with a remote dimmer. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
9 top-level lines · 24 rows shown · 384 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Backing Board 2 parts | neon-sign-backing-board | 1× | 1 | 2 | assembly |
| 1.1 | Acrylic / PVC Panel | neon-sign-acrylic-panel | 1× | 1 | — | part |
| 1.2 | Drilled Hole Set | neon-sign-standoff-holes | 1× | 1 | — | part |
| 2 | LED Neon Flex Tube 2 parts | neon-sign-neon-flex-tube | 4× | 4 | 83 | assembly |
| 2.1 | Flexible LED Strip 4 parts | neon-sign-flex-strip | 1× | 4 | 82 | assembly |
| 2.1.1 | Bare PCB | pcb-bare | 1× | 4 | — | part |
| 2.1.2 | SMD LED | neon-sign-smd-led | 60× | 240 | — | part |
| 2.1.3 | SMD Passive (R/C/L) | smd-passives | 20× | 80 | — | part |
| 2.1.4 | Strip Adhesive Tape | neon-sign-strip-adhesive | 1× | 4 | — | part |
| 2.2 | Silicone Diffuser Tube | neon-sign-silicone-tube | 1× | 4 | — | part |
| 3 | Mounting Clip / Channel | neon-sign-mounting-channel | 4× | 4 | — | part |
| 4 | Interconnect Wiring 2 parts | neon-sign-wiring | 1× | 1 | 2 | assembly |
| 4.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 4.2 | Solder | neon-sign-solder | 1× | 1 | — | part |
| 5 | End Cap & Sealant Kit 2 parts | neon-sign-end-cap-kit | 1× | 1 | 9 | assembly |
| 5.1 | End Cap | neon-sign-end-cap | 8× | 8 | — | part |
| 5.2 | Silicone Sealant | neon-sign-sealant | 1× | 1 | — | part |
| 6 | Power Supply | power-supply | 1× | 1 | — | part |
| 7 | Dimmer / RF Controller 3 parts | neon-sign-controller | 1× | 1 | 32 | assembly |
| 7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.2 | SMD Passive (R/C/L) | smd-passives | 30× | 30 | — | part |
| 7.3 | Wireless Remote | neon-sign-remote | 1× | 1 | — | part |
| 8 | Connector | connector | 1× | 1 | — | part |
| 9 | Fastener Set | fastener-set | 1× | 1 | — | part |
