Mountain Bike Product
A full-suspension trail mountain bike with a front/rear suspension system, hydraulic disc brakes, and a 1x wide-range drivetrain. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 59 rows shown · 193 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Suspension Frame 5 parts | mtb-frame | 1× | 1 | 11 | assembly |
| 1.1 | Front Triangle | mtb-front-triangle | 1× | 1 | — | part |
| 1.2 | Rear Triangle (Swingarm) | mtb-rear-triangle | 1× | 1 | — | part |
| 1.3 | Ball Bearing | ball-bearing | 6× | 6 | — | part |
| 1.4 | Shock Mount | mtb-shock-mount | 2× | 2 | — | part |
| 1.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Air Rear Shock 4 parts | mtb-rear-shock | 1× | 1 | 4 | assembly |
| 2.1 | Shock Air Can | mtb-shock-air-can | 1× | 1 | — | part |
| 2.2 | Shock Damper Body | mtb-shock-damper | 1× | 1 | — | part |
| 2.3 | Coil Spring | coil-spring | 1× | 1 | — | part |
| 2.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3 | Suspension Fork 6 parts | mtb-fork | 1× | 1 | 7 | assembly |
| 3.1 | Crown & Steerer | mtb-fork-crown-steerer | 1× | 1 | — | part |
| 3.2 | Fork Stanchion | mtb-fork-stanchion | 2× | 2 | — | part |
| 3.3 | Fork Lowers | mtb-fork-lowers | 1× | 1 | — | part |
| 3.4 | Fork Air Spring | mtb-fork-air-spring | 1× | 1 | — | part |
| 3.5 | Damper Cartridge | mtb-fork-damper | 1× | 1 | — | part |
| 3.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 4 | Wheel 6 parts | mtb-wheel | 2× | 2 | 65 | assembly |
| 4.1 | Hub 3 parts | mtb-hub | 1× | 2 | 6 | assembly |
| 4.1.1 | Hub Shell | mtb-hub-shell | 1× | 2 | — | part |
| 4.1.2 | Ball Bearing | ball-bearing | 4× | 8 | — | part |
| 4.1.3 | Freehub Body | mtb-freehub | 1× | 2 | — | part |
| 4.2 | Rim | mtb-rim | 1× | 2 | — | part |
| 4.3 | Spoke | mtb-spoke | 28× | 56 | — | part |
| 4.4 | Spoke Nipple | mtb-nipple | 28× | 56 | — | part |
| 4.5 | Tubeless Tire | mtb-tire | 1× | 2 | — | part |
| 4.6 | Tubeless Valve | mtb-valve | 1× | 2 | — | part |
| 5 | Drivetrain 8 parts | mtb-drivetrain | 1× | 1 | 13 | assembly |
| 5.1 | Crank Arm | mtb-crank-arm | 2× | 2 | — | part |
| 5.2 | Chainring | mtb-chainring | 1× | 1 | — | part |
| 5.3 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 5.4 | Pedal | mtb-pedal | 2× | 2 | — | part |
| 5.5 | Chain | mtb-chain | 1× | 1 | — | part |
| 5.6 | Cassette | mtb-cassette | 1× | 1 | — | part |
| 5.7 | Rear Derailleur 2 parts | mtb-rear-derailleur | 1× | 1 | 3 | assembly |
| 5.7.1 | Jockey Wheel | mtb-jockey-wheel | 2× | 2 | — | part |
| 5.7.2 | Coil Spring | coil-spring | 1× | 1 | — | part |
| 5.8 | Shifter | mtb-shifter | 1× | 1 | — | part |
| 6 | Hydraulic Disc Brake System 4 parts | mtb-brake | 1× | 1 | 16 | assembly |
| 6.1 | Brake Lever | mtb-brake-lever | 2× | 2 | — | part |
| 6.2 | Brake Caliper 3 parts | mtb-brake-caliper | 2× | 2 | 5 | assembly |
| 6.2.1 | Caliper Piston | mtb-caliper-piston | 2× | 4 | — | part |
| 6.2.2 | Brake Pad | mtb-brake-pad | 2× | 4 | — | part |
| 6.2.3 | O-Ring Set | oring-set | 1× | 2 | — | part |
| 6.3 | Brake Rotor | mtb-brake-rotor | 2× | 2 | — | part |
| 6.4 | Brake Hose | mtb-brake-hose | 2× | 2 | — | part |
| 7 | Cockpit 4 parts | mtb-cockpit | 1× | 1 | 6 | assembly |
| 7.1 | Handlebar | mtb-handlebar | 1× | 1 | — | part |
| 7.2 | Stem | mtb-stem | 1× | 1 | — | part |
| 7.3 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 7.4 | Grip | mtb-grip | 2× | 2 | — | part |
| 8 | Dropper Seatpost 4 parts | mtb-dropper-post | 1× | 1 | 4 | assembly |
| 8.1 | Dropper Post Mast | mtb-dropper-mast | 1× | 1 | — | part |
| 8.2 | Dropper Cartridge | mtb-dropper-cartridge | 1× | 1 | — | part |
| 8.3 | Dropper Remote Lever | mtb-dropper-lever | 1× | 1 | — | part |
| 8.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 9 | Saddle | mtb-saddle | 1× | 1 | — | part |
| 10 | Fastener Set | fastener-set | 1× | 1 | — | part |
