Veterinary Vital Signs Monitor Product

A portable multiparameter monitor for animals displaying ECG, SpO2, NIBP, temperature, EtCO2, and respiration with species-specific probes and audible/visual alarms. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

16 top-level lines · 80 rows shown · 858 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Housing 3 parts vet-monitor-housing 1× 1 3 assembly
1.1 Case + Handle vet-monitor-case 1× 1 — part
1.2 Stand/VESA Mount + Pole Clamp vet-monitor-stand-mount 1× 1 — part
1.3 Fastener Set fastener-set 1× 1 — part
2 Display Assembly 3 parts vet-monitor-display 1× 1 3 assembly
2.1 LCD Panel lcd-panel 1× 1 — part
2.2 Touch Digitizer touch-digitizer 1× 1 — part
2.3 Display Bezel + Backlight vet-monitor-bezel 1× 1 — part
3 Main Board 6 parts vet-monitor-main-board 1× 1 252 assembly
3.1 Bare PCB pcb-bare 1× 1 — part
3.2 Compute SoC Module soc-module 1× 1 — part
3.3 Microcontroller mcu 1× 1 — part
3.4 RAM + Flash Memory vet-monitor-memory 1× 1 — part
3.5 SMD Passive (R/C/L) smd-passives 240× 240 — part
3.6 Connector connector 8× 8 — part
4 Parameter Acquisition Board 5 parts vet-monitor-acquisition-board 1× 1 161 assembly
4.1 Bare PCB pcb-bare 1× 1 — part
4.2 Microcontroller mcu 1× 1 — part
4.3 Patient Isolation Barrier vet-monitor-isolation-barrier 1× 1 — part
4.4 SMD Passive (R/C/L) smd-passives 150× 150 — part
4.5 Connector connector 8× 8 — part
5 ECG Module 5 parts vet-monitor-ecg-module 1× 1 78 assembly
5.1 Bare PCB pcb-bare 1× 1 — part
5.2 Patient Isolation Barrier vet-monitor-isolation-barrier 1× 1 — part
5.3 ECG Lead Wire Set vet-monitor-ecg-leadwire 1× 1 — part
5.4 ECG Atraumatic Clip vet-monitor-ecg-clip 5× 5 — part
5.5 SMD Passive (R/C/L) smd-passives 70× 70 — part
6 SpO2 Module 3 parts vet-monitor-spo2-module 1× 1 53 assembly
6.1 Bare PCB pcb-bare 1× 1 — part
6.2 SpO2 Paw/Tongue Probe 2 parts vet-monitor-spo2-probe 1× 1 2 assembly
6.2.1 Paw/Tongue Clip + Optics vet-monitor-probe-clip 1× 1 — part
6.2.2 Wire Bundle wire-bundle 1× 1 — part
6.3 SMD Passive (R/C/L) smd-passives 50× 50 — part
7 NIBP Module 6 parts vet-monitor-nibp-module 1× 1 65 assembly
7.1 Bare PCB pcb-bare 1× 1 — part
7.2 Microcontroller mcu 1× 1 — part
7.3 Blower Motor blower-motor 1× 1 — part
7.4 NIBP Valve + Pressure Sensor vet-monitor-nibp-valve 1× 1 — part
7.5 Veterinary BP Cuff vet-monitor-nibp-cuff 1× 1 — part
7.6 SMD Passive (R/C/L) smd-passives 60× 60 — part
8 Temperature Module 3 parts vet-monitor-temp-module 1× 1 32 assembly
8.1 Bare PCB pcb-bare 1× 1 — part
8.2 Rectal Temperature Probe vet-monitor-temp-probe 1× 1 — part
8.3 SMD Passive (R/C/L) smd-passives 30× 30 — part
9 EtCO2 Capnography Module 6 parts vet-monitor-etco2-module 1× 1 60 assembly
9.1 Bare PCB pcb-bare 1× 1 — part
9.2 Microcontroller mcu 1× 1 — part
9.3 NDIR CO2 Optical Bench vet-monitor-co2-bench 1× 1 — part
9.4 Blower Motor blower-motor 1× 1 — part
9.5 CO2 Sampling Line + Water Trap vet-monitor-co2-sampling-line 1× 1 — part
9.6 SMD Passive (R/C/L) smd-passives 55× 55 — part
10 Respiration Module 2 parts vet-monitor-resp-module 1× 1 41 assembly
10.1 Bare PCB pcb-bare 1× 1 — part
10.2 SMD Passive (R/C/L) smd-passives 40× 40 — part
11 Alarm Unit 4 parts vet-monitor-alarm-unit 1× 1 30 assembly
11.1 Speaker speaker 1× 1 — part
11.2 Alarm Indicator LED vet-monitor-alarm-led 3× 3 — part
11.3 Bare PCB pcb-bare 1× 1 — part
11.4 SMD Passive (R/C/L) smd-passives 25× 25 — part
12 Power System 4 parts vet-monitor-power-system 1× 1 14 assembly
12.1 Medical AC-DC Power Supply vet-monitor-power-supply 1× 1 — part
12.2 Rechargeable Battery Pack 3 parts vet-monitor-battery-pack 1× 1 6 assembly
12.2.1 LiPo Cell lipo-cell 3× 3 — part
12.2.2 BMS Board bms-board 1× 1 — part
12.2.3 Connector connector 2× 2 — part
12.3 Wire Bundle wire-bundle 1× 1 — part
12.4 Connector connector 6× 6 — part
13 Control Panel 3 parts vet-monitor-control-panel 1× 1 22 assembly
13.1 Membrane Keypad + Encoder Knob vet-monitor-keypad 1× 1 — part
13.2 Bare PCB pcb-bare 1× 1 — part
13.3 SMD Passive (R/C/L) smd-passives 20× 20 — part
14 Ports Panel 2 parts vet-monitor-ports-panel 1× 1 9 assembly
14.1 Connector connector 8× 8 — part
14.2 Patient Isolation Barrier vet-monitor-isolation-barrier 1× 1 — part
15 WiFi Module 4 parts vet-monitor-wifi-module 1× 1 34 assembly
15.1 Bare PCB pcb-bare 1× 1 — part
15.2 WiFi/Bluetooth Radio + Antenna vet-monitor-wifi-radio 1× 1 — part
15.3 SMD Passive (R/C/L) smd-passives 30× 30 — part
15.4 Connector connector 2× 2 — part
16 Wire Bundle wire-bundle 1× 1 — part

Sourcing — likely vendors

Companies that make this · indicative price $200–$200k · MOQ & lead are typical
VendorHQSpecialtyMOQLead time
🇺🇸Dentsply Sirona
dentsplysirona.com ↗ 		Charlotte, US Dental equipment 100 units 10–16 wks
🇺🇸Envista
envistaco.com ↗ 		Brea, US Dental (KaVo, Nobel) 100 units 10–16 wks
🇫🇮Planmeca
planmeca.com ↗ 		Helsinki, FI Dental units & imaging 100 units 10–16 wks
🇺🇸A-dec
a-dec.com ↗ 		Newberg, US Dental chairs & delivery 100 units 10–16 wks
🇺🇸Midmark
midmark.com ↗ 		Versailles, US Medical & veterinary equipment 100 units 10–16 wks
