Dental X-Ray Unit Product
A wall-mounted panoramic/intraoral dental X-ray system with a rotating C-arm and digital CMOS detector. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 71 rows shown · 113 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Wall Column Mount 3 parts | dental-xray-mount | 1× | 1 | 27 | assembly |
| 1.1 | Telescopic Column | dental-xray-column | 1× | 1 | — | part |
| 1.2 | Column Lift Motor 4 parts | dental-xray-lift-motor | 1× | 1 | 24 | assembly |
| 1.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 1.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 1.2.3 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 1.2.4 | Microcontroller | mcu | 1× | 1 | — | part |
| 1.3 | Fastener Set | fastener-set | 2× | 2 | — | part |
| 2 | Articulating Extension Arm 5 parts | dental-xray-arm | 1× | 1 | 10 | assembly |
| 2.1 | Extension Arm | dental-xray-extension-arm | 1× | 1 | — | part |
| 2.2 | Arm Joint | dental-xray-arm-joint | 2× | 2 | — | part |
| 2.3 | Balance Spring | dental-xray-balance-spring | 2× | 2 | — | part |
| 2.4 | Ball Bearing | ball-bearing | 4× | 4 | — | part |
| 2.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 3 | X-Ray Tubehead 6 parts | dental-xray-tubehead | 1× | 1 | 14 | assembly |
| 3.1 | X-Ray Tube 3 parts | dental-xray-tube | 1× | 1 | 3 | assembly |
| 3.1.1 | Stationary Anode | dental-xray-stationary-anode | 1× | 1 | — | part |
| 3.1.2 | Tungsten Filament | dental-xray-filament | 1× | 1 | — | part |
| 3.1.3 | Glass Envelope | dental-xray-glass-envelope | 1× | 1 | — | part |
| 3.2 | Tube Housing | dental-xray-tube-housing | 1× | 1 | — | part |
| 3.3 | Dielectric Cooling Oil | dental-xray-tube-oil | 1× | 1 | — | part |
| 3.4 | HV Generator Board 5 parts | dental-xray-hv-generator | 1× | 1 | 7 | assembly |
| 3.4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.4.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.4.3 | HV Transformer | dental-xray-hv-transformer | 1× | 1 | — | part |
| 3.4.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.4.5 | Connector | connector | 3× | 3 | — | part |
| 3.5 | Collimator / Cone | dental-xray-collimator | 1× | 1 | — | part |
| 3.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 4 | Rotating Panoramic Gantry 5 parts | dental-xray-gantry | 1× | 1 | 28 | assembly |
| 4.1 | C-Arm | dental-xray-c-arm | 1× | 1 | — | part |
| 4.2 | Gantry Rotation Motor 3 parts | dental-xray-rotation-motor | 1× | 1 | 23 | assembly |
| 4.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 4.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 4.2.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 4.3 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 4.4 | Drive Belt | dental-xray-drive-belt | 1× | 1 | — | part |
| 4.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 5 | Patient Positioning Assembly 5 parts | dental-xray-positioning | 1× | 1 | 9 | assembly |
| 5.1 | Chin Rest | dental-xray-chin-rest | 1× | 1 | — | part |
| 5.2 | Bite Block | dental-xray-bite-block | 1× | 1 | — | part |
| 5.3 | Temple Support | dental-xray-temple-support | 2× | 2 | — | part |
| 5.4 | Laser Positioning Lights 2 parts | dental-xray-laser-positioner | 1× | 1 | 4 | assembly |
| 5.4.1 | Line-Laser Module | dental-xray-laser-module | 3× | 3 | — | part |
| 5.4.2 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 6 | Digital CMOS Sensor 4 parts | dental-xray-detector | 1× | 1 | 8 | assembly |
| 6.1 | Scintillator | dental-xray-scintillator | 1× | 1 | — | part |
| 6.2 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 6.3 | Detector Readout Board 4 parts | dental-xray-readout-board | 1× | 1 | 5 | assembly |
| 6.3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.3.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 6.3.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 6.3.4 | Connector | connector | 2× | 2 | — | part |
| 6.4 | Power Supply | power-supply | 1× | 1 | — | part |
| 7 | Control Panel 5 parts | dental-xray-control-panel | 1× | 1 | 6 | assembly |
| 7.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 7.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 7.3 | Exposure Button 2 parts | dental-xray-exposure-button | 1× | 1 | 2 | assembly |
| 7.3.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 7.3.2 | Connector | connector | 1× | 1 | — | part |
| 7.4 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.5 | Microcontroller | mcu | 1× | 1 | — | part |
| 8 | Power Supply | power-supply | 1× | 1 | — | part |
| 9 | Tubehead Cooling Fan 2 parts | dental-xray-cooling | 1× | 1 | 2 | assembly |
| 9.1 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 9.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 10 | HV & Signal Cabling 3 parts | dental-xray-cabling | 1× | 1 | 8 | assembly |
| 10.1 | High-Voltage Cable | dental-xray-hv-cable | 1× | 1 | — | part |
| 10.2 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 10.3 | Connector | connector | 6× | 6 | — | part |
