Foam Dart Blaster Product
A motorized flywheel foam-dart blaster: twin flywheels accelerate darts that a motorized pusher feeds from a detachable magazine. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
11 top-level lines · 48 rows shown · 155 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Clamshell Housing 4 parts | nerf-blaster-shell | 1× | 1 | 4 | assembly |
| 1.1 | Left Half Shell | nerf-blaster-left-shell | 1× | 1 | — | part |
| 1.2 | Right Half Shell | nerf-blaster-right-shell | 1× | 1 | — | part |
| 1.3 | Pistol Grip | nerf-blaster-grip | 1× | 1 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Flywheel System 5 parts | nerf-blaster-flywheel-system | 1× | 1 | 51 | assembly |
| 2.1 | Flywheel Motor 3 parts | nerf-blaster-flywheel-motor | 2× | 2 | 23 | assembly |
| 2.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 2 | 3 | assembly |
| 2.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 2 | 19 | assembly |
| 2.1.3 | Motor Housing | motor-housing | 1× | 2 | — | part |
| 2.2 | Flywheel | nerf-blaster-flywheel | 2× | 2 | — | part |
| 2.3 | Flywheel Cage | nerf-blaster-flywheel-cage | 1× | 1 | — | part |
| 2.4 | Rev Trigger | nerf-blaster-rev-trigger | 1× | 1 | — | part |
| 2.5 | Rev Microswitch | nerf-blaster-rev-switch | 1× | 1 | — | part |
| 3 | Pusher Mechanism 4 parts | nerf-blaster-pusher-mechanism | 1× | 1 | 28 | assembly |
| 3.1 | Pusher Motor 3 parts | nerf-blaster-pusher-motor | 1× | 1 | 23 | assembly |
| 3.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 3.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 3.1.3 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 3.2 | Pusher Gearbox 3 parts | nerf-blaster-pusher-gearbox | 1× | 1 | 3 | assembly |
| 3.2.1 | Reduction Gear Set | nerf-blaster-gear-set | 1× | 1 | — | part |
| 3.2.2 | Pusher Cam | nerf-blaster-pusher-cam | 1× | 1 | — | part |
| 3.2.3 | Gearbox Shell | nerf-blaster-gearbox-shell | 1× | 1 | — | part |
| 3.3 | Pusher Rod | nerf-blaster-pusher-rod | 1× | 1 | — | part |
| 3.4 | Coil Spring | coil-spring | 1× | 1 | — | part |
| 4 | Detachable Magazine 5 parts | nerf-blaster-magazine | 1× | 1 | 16 | assembly |
| 4.1 | Magazine Well | nerf-blaster-mag-well | 1× | 1 | — | part |
| 4.2 | Magazine Shell | nerf-blaster-mag-shell | 1× | 1 | — | part |
| 4.3 | Magazine Follower | nerf-blaster-follower | 1× | 1 | — | part |
| 4.4 | Coil Spring | coil-spring | 1× | 1 | — | part |
| 4.5 | Foam Dart | nerf-blaster-dart | 12× | 12 | — | part |
| 5 | Trigger Group 3 parts | nerf-blaster-trigger-group | 1× | 1 | 3 | assembly |
| 5.1 | Main Trigger | nerf-blaster-trigger | 1× | 1 | — | part |
| 5.2 | Trigger Microswitch | nerf-blaster-trigger-switch | 1× | 1 | — | part |
| 5.3 | Safety Lockout | nerf-blaster-safety-lockout | 1× | 1 | — | part |
| 6 | Control Board 4 parts | nerf-blaster-control-board | 1× | 1 | 36 | assembly |
| 6.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2 | Power MOSFET | mosfet | 2× | 2 | — | part |
| 6.3 | SMD Passive (R/C/L) | smd-passives | 30× | 30 | — | part |
| 6.4 | Connector | connector | 3× | 3 | — | part |
| 7 | Battery Tray 3 parts | nerf-blaster-battery-tray | 1× | 1 | 13 | assembly |
| 7.1 | Li-ion Cell, 18650 | li-cell-18650 | 4× | 4 | — | part |
| 7.2 | Battery Contact | nerf-blaster-battery-contact | 8× | 8 | — | part |
| 7.3 | Battery Tray Shell | nerf-blaster-tray-shell | 1× | 1 | — | part |
| 8 | Barrel Shroud / Muzzle | nerf-blaster-barrel | 1× | 1 | — | part |
| 9 | Tactical Rail Set | nerf-blaster-rail-set | 1× | 1 | — | part |
| 10 | Jam-Clearance Door | nerf-blaster-jam-door | 1× | 1 | — | part |
| 11 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $20–$3k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| 🇺🇸Hasbro hasbro.com ↗ | Pawtucket, US | Toys & games | 2,000 units | 6–10 wks |
| 🇨🇳Worker workergun.com ↗ | Shenzhen, CN | Foam blasters & dart mods | 2,000 units | 6–10 wks |
