Slot Car Racing Set Product

1/32-scale analog slot car racing set: a snap-together track loop with conductor rails and a lap counter, two electrically driven slot cars, a transformer power feed and two trigger hand controllers that vary track voltage to race the cars. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

6 top-level lines · 49 rows shown · 182 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Track System 4 parts slot-car-set-track-system 1× 1 66 assembly
1.1 Track Section 2 parts slot-car-set-track-section 14× 14 3 assembly
1.1.1 Track Section Base slot-car-set-track-base 1× 14 — part
1.1.2 Conductor Rail / Braid Strip slot-car-set-conductor-rail 2× 28 — part
1.2 Crossover Section 2 parts slot-car-set-track-crossover 1× 1 5 assembly
1.2.1 Track Section Base slot-car-set-track-base 1× 1 — part
1.2.2 Conductor Rail / Braid Strip slot-car-set-conductor-rail 4× 4 — part
1.3 Lap-Counter Bridge 5 parts slot-car-set-lap-bridge 1× 1 7 assembly
1.3.1 Bridge Frame & Display slot-car-set-bridge-frame 1× 1 — part
1.3.2 Bare PCB pcb-bare 1× 1 — part
1.3.3 Lap Sensor slot-car-set-lap-sensor 2× 2 — part
1.3.4 Wire Bundle wire-bundle 1× 1 — part
1.3.5 Connector connector 2× 2 — part
1.4 Border / Barrier slot-car-set-border-barrier 12× 12 — part
2 Slot Car 8 parts slot-car-set-car 2× 2 46 assembly
2.1 Body Shell slot-car-set-body-shell 1× 2 — part
2.2 Window Glazing slot-car-set-window-glazing 1× 2 — part
2.3 Interior Tray slot-car-set-interior 1× 2 — part
2.4 Chassis 3 parts slot-car-set-chassis 1× 2 7 assembly
2.4.1 Chassis Pan slot-car-set-chassis-pan 1× 2 — part
2.4.2 Axle slot-car-set-axle 2× 4 — part
2.4.3 Wheel Hub & Tyre slot-car-set-wheel 4× 8 — part
2.5 Can Motor 5 parts slot-car-set-motor 1× 2 27 assembly
2.5.1 Stator Assembly 3 parts + deeper › stator-assembly 1× 2 3 assembly
2.5.2 Rotor Assembly 4 parts + deeper › rotor-assembly 1× 2 19 assembly
2.5.3 Motor Housing motor-housing 1× 2 — part
2.5.4 Neodymium Magnet neodymium-magnet 2× 4 — part
2.5.5 Motor Brush slot-car-set-motor-brush 2× 4 — part
2.6 Helical Gear Pair gear-pair 1× 2 — part
2.7 Guide Assembly 3 parts slot-car-set-guide-assembly 1× 2 4 assembly
2.7.1 Guide Blade / Keel slot-car-set-guide-blade 1× 2 — part
2.7.2 Pickup Braid slot-car-set-pickup-braid 2× 4 — part
2.7.3 Wire Bundle wire-bundle 1× 2 — part
2.8 LED Light slot-car-set-led 4× 8 — part
3 Power Feed 4 parts slot-car-set-power-feed 1× 1 5 assembly
3.1 Power Supply power-supply 1× 1 — part
3.2 Power Terminal Section slot-car-set-power-base 1× 1 — part
3.3 Connector connector 2× 2 — part
3.4 Wire Bundle wire-bundle 1× 1 — part
4 Hand Controller 5 parts slot-car-set-controller 2× 2 5 assembly
4.1 Controller Housing slot-car-set-controller-housing 1× 2 — part
4.2 Trigger slot-car-set-trigger 1× 2 — part
4.3 Rheostat slot-car-set-rheostat 1× 2 — part
4.4 Connector connector 1× 2 — part
4.5 Wire Bundle wire-bundle 1× 2 — part
5 Spares Pack 2 parts slot-car-set-spares-pack 1× 1 8 assembly
5.1 Pickup Braid slot-car-set-pickup-braid 4× 4 — part
5.2 Wheel Hub & Tyre slot-car-set-wheel 4× 4 — part
6 Fastener Set fastener-set 1× 1 — part
