FPV Racing Drone Product
A 5-inch carbon-frame FPV freestyle and racing quadcopter with goggles and radio. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
14 top-level lines · 89 rows shown · 278 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Carbon Frame 6 parts | fpv-racing-drone-frame | 1× | 1 | 12 | assembly |
| 1.1 | Top Plate | fpv-racing-drone-top-plate | 1× | 1 | — | part |
| 1.2 | Bottom Plate | fpv-racing-drone-bottom-plate | 1× | 1 | — | part |
| 1.3 | Frame Arm | fpv-racing-drone-arm | 4× | 4 | — | part |
| 1.4 | Standoff | fpv-racing-drone-standoff | 4× | 4 | — | part |
| 1.5 | Camera Mount | fpv-racing-drone-camera-mount | 1× | 1 | — | part |
| 1.6 | TPU Printed Parts | fpv-racing-drone-tpu-parts | 1× | 1 | — | part |
| 2 | Brushless Motor 6 parts | fpv-racing-drone-motor | 4× | 4 | 40 | assembly |
| 2.1 | Stator Assembly 3 parts | stator-assembly | 1× | 4 | 3 | assembly |
| 2.1.1 | Stator Core (laminations) | stator-core | 1× | 4 | — | part |
| 2.1.2 | Copper Winding | copper-winding | 1× | 4 | — | part |
| 2.1.3 | Slot Insulation | stator-insulation | 1× | 4 | — | part |
| 2.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 4 | 19 | assembly |
| 2.2.1 | Rotor Shaft | rotor-shaft | 1× | 4 | — | part |
| 2.2.2 | Rotor Core | rotor-core | 1× | 4 | — | part |
| 2.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 64 | — | part |
| 2.2.4 | Ball Bearing | ball-bearing | 1× | 4 | — | part |
| 2.3 | Copper Winding | copper-winding | 1× | 4 | — | part |
| 2.4 | Neodymium Magnet | neodymium-magnet | 14× | 56 | — | part |
| 2.5 | Ball Bearing | ball-bearing | 2× | 8 | — | part |
| 2.6 | Motor Bell | fpv-racing-drone-motor-bell | 1× | 4 | — | part |
| 3 | 4-in-1 ESC 5 parts | fpv-racing-drone-esc-4in1 | 1× | 1 | 40 | assembly |
| 3.1 | ESC 4 parts | esc | 4× | 4 | 9 | assembly |
| 3.1.1 | Bare PCB | pcb-bare | 1× | 4 | — | part |
| 3.1.2 | Power MOSFET | mosfet | 6× | 24 | — | part |
| 3.1.3 | Gate Driver IC | gate-driver-ic | 1× | 4 | — | part |
| 3.1.4 | Microcontroller | mcu | 1× | 4 | — | part |
| 3.2 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.3 | Bus Capacitor | fpv-racing-drone-capacitor | 1× | 1 | — | part |
| 3.4 | XT60 Connector | xt60-connector | 1× | 1 | — | part |
| 3.5 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 4 | Propeller | propeller | 4× | 4 | — | part |
| 5 | Flight Controller 7 parts | fpv-racing-drone-flight-controller | 1× | 1 | 10 | assembly |
| 5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 5.3 | IMU (6-axis) | imu | 1× | 1 | — | part |
| 5.4 | Barometer | barometer | 1× | 1 | — | part |
| 5.5 | OSD Chip | fpv-racing-drone-osd-chip | 1× | 1 | — | part |
| 5.6 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 5.7 | Connector | connector | 4× | 4 | — | part |
| 6 | FPV System 3 parts | fpv-racing-drone-fpv-system | 1× | 1 | 9 | assembly |
| 6.1 | FPV Camera 3 parts | fpv-racing-drone-fpv-camera | 1× | 1 | 5 | assembly |
| 6.1.1 | Camera Module 3 parts + deeper › | camera-module | 1× | 1 | 3 | assembly |
| 6.1.2 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 6.1.3 | Camera Lens | fpv-racing-drone-camera-lens | 1× | 1 | — | part |
| 6.2 | Video Transmitter 3 parts | fpv-racing-drone-vtx | 1× | 1 | 3 | assembly |
| 6.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2.2 | RF Power Amplifier | fpv-racing-drone-rf-amp | 1× | 1 | — | part |
| 6.2.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 6.3 | VTX Antenna | fpv-racing-drone-vtx-antenna | 1× | 1 | — | part |
| 7 | Radio Receiver 2 parts | fpv-racing-drone-receiver | 1× | 1 | 2 | assembly |
| 7.1 | Receiver Module | fpv-racing-drone-rx-module | 1× | 1 | — | part |
| 7.2 | Receiver Antenna | fpv-racing-drone-rx-antenna | 1× | 1 | — | part |
| 8 | LiPo Battery 4 parts | fpv-racing-drone-battery | 1× | 1 | 9 | assembly |
| 8.1 | LiPo Cell | lipo-cell | 6× | 6 | — | part |
| 8.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 8.3 | XT60 Connector | xt60-connector | 1× | 1 | — | part |
| 8.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 9 | Buzzer & LED Strip 2 parts | fpv-racing-drone-buzzer-led | 1× | 1 | 2 | assembly |
| 9.1 | Buzzer | fpv-racing-drone-buzzer | 1× | 1 | — | part |
| 9.2 | LED Strip | fpv-racing-drone-led-strip | 1× | 1 | — | part |
| 10 | GPS Module 3 parts | fpv-racing-drone-gps | 1× | 1 | 3 | assembly |
| 10.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 10.2 | GNSS Chip | fpv-racing-drone-gnss-chip | 1× | 1 | — | part |
| 10.3 | GPS Antenna | fpv-racing-drone-gps-antenna | 1× | 1 | — | part |
| 11 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 12 | FPV Goggles 4 parts | fpv-racing-drone-goggles | 1× | 1 | 11 | assembly |
| 12.1 | Goggle Display | fpv-racing-drone-goggle-display | 2× | 2 | — | part |
| 12.2 | Goggle Video Receiver 2 parts | fpv-racing-drone-goggle-rx | 1× | 1 | 2 | assembly |
| 12.2.1 | Receiver Module | fpv-racing-drone-rx-module | 1× | 1 | — | part |
| 12.2.2 | VTX Antenna | fpv-racing-drone-vtx-antenna | 1× | 1 | — | part |
| 12.3 | Goggle Mainboard 3 parts | fpv-racing-drone-goggle-pcb | 1× | 1 | 3 | assembly |
| 12.3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 12.3.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 12.3.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 12.4 | Goggle Battery 3 parts | fpv-racing-drone-goggle-battery | 1× | 1 | 4 | assembly |
| 12.4.1 | LiPo Cell | lipo-cell | 2× | 2 | — | part |
| 12.4.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 12.4.3 | Connector | connector | 1× | 1 | — | part |
| 13 | Radio Transmitter 5 parts | fpv-racing-drone-radio-tx | 1× | 1 | 9 | assembly |
| 13.1 | Gimbal Stick | fpv-racing-drone-gimbal-stick | 2× | 2 | — | part |
| 13.2 | Transmitter Mainboard 3 parts | fpv-racing-drone-tx-pcb | 1× | 1 | 3 | assembly |
| 13.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 13.2.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 13.2.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 13.3 | TX RF Module | fpv-racing-drone-tx-module | 1× | 1 | — | part |
| 13.4 | Receiver Antenna | fpv-racing-drone-rx-antenna | 1× | 1 | — | part |
| 13.5 | LiPo Cell | lipo-cell | 2× | 2 | — | part |
| 14 | Fastener Set | fastener-set | 6× | 6 | — | part |
