DJ Controller Product
A two-deck USB DJ controller with motorized-feel jog wheels, a built-in 24-bit audio interface, channel mixer and performance pad grid. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
12 top-level lines · 62 rows shown · 179 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Chassis & Enclosure 5 parts | dj-controller-chassis | 1× | 1 | 9 | assembly |
| 1.1 | Aluminium Top Plate | dj-controller-top-plate | 1× | 1 | — | part |
| 1.2 | Plastic Base Tub | dj-controller-base | 1× | 1 | — | part |
| 1.3 | Side Panel | dj-controller-side-panel | 2× | 2 | — | part |
| 1.4 | Rubber Foot | dj-controller-foot | 4× | 4 | — | part |
| 1.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Jog Wheel 6 parts | dj-controller-jog-wheel | 2× | 2 | 6 | assembly |
| 2.1 | Weighted Platter | dj-controller-platter | 1× | 2 | — | part |
| 2.2 | Capacitive Touch Top | dj-controller-touch-top | 1× | 2 | — | part |
| 2.3 | Jog Center Display | dj-controller-jog-display | 1× | 2 | — | part |
| 2.4 | Jog Encoder | dj-controller-jog-encoder | 1× | 2 | — | part |
| 2.5 | Ball Bearing | ball-bearing | 1× | 2 | — | part |
| 2.6 | Fastener Set | fastener-set | 1× | 2 | — | part |
| 3 | Mixer Section 8 parts | dj-controller-mixer | 1× | 1 | 27 | assembly |
| 3.1 | Channel Line Fader | dj-controller-channel-fader | 2× | 2 | — | part |
| 3.2 | Crossfader | dj-controller-crossfader | 1× | 1 | — | part |
| 3.3 | Potentiometer | dj-controller-pot | 8× | 8 | — | part |
| 3.4 | Potentiometer | dj-controller-pot | 2× | 2 | — | part |
| 3.5 | Knob Cap | dj-controller-knob-cap | 10× | 10 | — | part |
| 3.6 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.7 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.8 | Connector | connector | 2× | 2 | — | part |
| 4 | Performance Pad Bank 6 parts | dj-controller-pad-section | 2× | 2 | 27 | assembly |
| 4.1 | Silicone Performance Pad | dj-controller-pad | 8× | 16 | — | part |
| 4.2 | RGB LED | dj-controller-rgb-led | 8× | 16 | — | part |
| 4.3 | Pad Switch | dj-controller-pad-switch | 8× | 16 | — | part |
| 4.4 | Pad PCB | dj-controller-pad-pcb | 1× | 2 | — | part |
| 4.5 | SMD Passive (R/C/L) | smd-passives | 1× | 2 | — | part |
| 4.6 | Connector | connector | 1× | 2 | — | part |
| 5 | Deck Control Cluster 7 parts | dj-controller-deck-controls | 2× | 2 | 22 | assembly |
| 5.1 | Control Button | dj-controller-button | 12× | 24 | — | part |
| 5.2 | Rotary Encoder | dj-controller-encoder | 3× | 6 | — | part |
| 5.3 | Tempo Fader | dj-controller-tempo-fader | 1× | 2 | — | part |
| 5.4 | Knob Cap | dj-controller-knob-cap | 3× | 6 | — | part |
| 5.5 | Bare PCB | pcb-bare | 1× | 2 | — | part |
| 5.6 | SMD Passive (R/C/L) | smd-passives | 1× | 2 | — | part |
| 5.7 | Connector | connector | 1× | 2 | — | part |
| 6 | Main Control Board 5 parts | dj-controller-control-board | 1× | 1 | 10 | assembly |
| 6.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 6.3 | Multichannel ADC | dj-controller-adc | 1× | 1 | — | part |
| 6.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 6.5 | Connector | connector | 6× | 6 | — | part |
| 7 | Audio Interface Board 6 parts | dj-controller-audio-board | 1× | 1 | 8 | assembly |
| 7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 7.3 | Audio Codec (DAC/ADC) | dj-controller-codec | 1× | 1 | — | part |
| 7.4 | Headphone Amplifier | dj-controller-headphone-amp | 1× | 1 | — | part |
| 7.5 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 7.6 | Connector | connector | 3× | 3 | — | part |
| 8 | I/O Panel 5 parts | dj-controller-io-panel | 1× | 1 | 10 | assembly |
| 8.1 | Jack Mounting Plate | dj-controller-jack-plate | 1× | 1 | — | part |
| 8.2 | Connector | connector | 4× | 4 | — | part |
| 8.3 | Connector | connector | 2× | 2 | — | part |
| 8.4 | Connector | connector | 2× | 2 | — | part |
| 8.5 | Connector | connector | 1× | 1 | — | part |
| 9 | Status Display 2 parts | dj-controller-display | 1× | 1 | 2 | assembly |
| 9.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 9.2 | Connector | connector | 1× | 1 | — | part |
| 10 | Power Supply | power-supply | 1× | 1 | — | part |
| 11 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 12 | Fastener Set | fastener-set | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $50–$5k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| yamaha.com ↗ | Hamamatsu, JP | Audio & instruments | 200 units | 8–14 wks |
| 🇺🇸Fender fender.com ↗ | Los Angeles, US | Guitars & amps | 200 units | 8–14 wks |
| 🇺🇸Gibson gibson.com ↗ | Nashville, US | Guitars | 200 units | 8–14 wks |
| 🇯🇵Roland roland.com ↗ | Hamamatsu, JP | Electronic instruments | 200 units | 8–14 wks |
| steinway.com ↗ | New York, US | Pianos | 200 units | 8–14 wks |
