Track Geometry Car

Product

Track geometry car · Commons ↗ Report photo

A measurement-equipped railway vehicle carrying laser, camera and sensor systems to monitor track alignment, profile and ride quality.

Vehicle type	Self-powered measurement coach
Measurement frequency	25–100 kHz laser sampling rate
Data points per km	100,000–500,000 depending on speed
Laser wavelength	Typically 650–850 nm (visible/IR)
Lateral accuracy	±1–2 mm at gauge and alignment
Vertical accuracy	±2–3 mm for profile and twist
Operating speed	5–40 km/h measurement speed
Imaging resolution	Line-scan 2048–4096 pixels
Data storage	1–2 TB SSD per 1000 km recording
Power supply	Pantograph 750 V DC or onboard 24 V battery
Wheelset load	10–15 tonnes total coach mass
Standards	EN 13848 (track geometry), various national railway RFCs
Direct parts	7
Total parts	122
Class	Product

Report a problem with this BOM

Overview

A track geometry measurement car is a specialised railway vehicle carrying laser, optical and acceleration sensors to measure the precise shape and alignment of the track bed. Every railway must monitor its track geometry periodically, the rail alignment, gauge, profile, cant, twist, and ride quality. Worn or misaligned track causes accelerated damage and increases energy consumption.

How it works

The Coach Body houses the sensor stack and data processing electronics. The two measurement bogies carry wheels at precisely measured axle spacing with stiff springs and dampers.

The Laser Measurement Head is a non-contact laser head mounted below the car. It emits a laser beam at the rail top, and a photodiode receiver detects the reflection. The system builds a point cloud of the rail profile at speeds of 10–20 km/h.

The Imaging & Lighting System captures high-resolution line-scan images with high-brightness LED lighting. The Data Acquisition System system samples laser signals and acceleration data synchronously.

Track Geometry Car parts and their functions

7 top-level parts · 122 parts in total · full bill of materials below

Track Geometry Car parts diagram: 1 measurement bogie, 2 coach body, 3 laser measurement head, 4 imaging & lighting system, 5 data acquisition system, 6 power & distribution, 7 vibration isolation system. 122 parts in 7 top-level items. — Track Geometry Car parts diagram. Numbers match the table below; each box is one top-level part or assembly with what it contains.

#	Part	Qty	What it does
1	Measurement Bogie 5 parts	2×	Front and rear wheel bogies
2	Coach Body 5 parts	1×	Coach superstructure and cabin
3	Laser Measurement Head 4 parts	1×	Primary sensor and laser assembly
4	Imaging & Lighting System 4 parts	1×	Line-scan camera and lighting
5	Data Acquisition System 4 parts	1×	Recording and processing electronics
6	Power & Distribution 3 parts	1×	Electrical supply and distribution
7	Vibration Isolation System 2 parts	1×	Vibration isolation system
