Shrink Wrap Machine Product

An automatic L-bar sealer and heat shrink tunnel that wraps products in polyolefin film and shrinks it to a tight, glossy package. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

10 top-level lines · 78 rows shown · 213 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Frame & Cabinet 4 parts shrink-wrap-machine-frame 1× 1 10 assembly
1.1 Base Weldment shrink-wrap-machine-base-weldment 1× 1 — part
1.2 Cabinet Panel shrink-wrap-machine-panel 4× 4 — part
1.3 Locking Caster shrink-wrap-machine-caster 4× 4 — part
1.4 Fastener Set fastener-set 1× 1 — part
2 Film Supply 4 parts shrink-wrap-machine-film-supply 1× 1 6 assembly
2.1 Film Roll Holder shrink-wrap-machine-film-roll-holder 1× 1 — part
2.2 Film Unwind 2 parts shrink-wrap-machine-film-unwind 1× 1 3 assembly
2.2.1 Ball Bearing ball-bearing 2× 2 — part
2.2.2 Coil Spring coil-spring 1× 1 — part
2.3 Film Folding Plow shrink-wrap-machine-film-plow 1× 1 — part
2.4 Film Perforator shrink-wrap-machine-perforator 1× 1 — part
3 Infeed Conveyor 5 parts shrink-wrap-machine-conveyor-infeed 1× 1 28 assembly
3.1 Infeed Belt & Seal Table shrink-wrap-machine-infeed-belt 1× 1 — part
3.2 Stator Assembly 3 parts stator-assembly 1× 1 3 assembly
3.2.1 Stator Core (laminations) stator-core 1× 1 — part
3.2.2 Copper Winding copper-winding 1× 1 — part
3.2.3 Slot Insulation stator-insulation 1× 1 — part
3.3 Rotor Assembly 4 parts rotor-assembly 1× 1 19 assembly
3.3.1 Rotor Shaft rotor-shaft 1× 1 — part
3.3.2 Rotor Core rotor-core 1× 1 — part
3.3.3 Neodymium Magnet neodymium-magnet 16× 16 — part
3.3.4 Ball Bearing ball-bearing 1× 1 — part
3.4 Drive Belt drive-belt 1× 1 — part
3.5 Ball Bearing ball-bearing 4× 4 — part
4 L-Bar Sealer 7 parts shrink-wrap-machine-lbar-sealer 1× 1 31 assembly
4.1 Seal Bar Arm shrink-wrap-machine-seal-arm 1× 1 — part
4.2 Heating Element heating-element 1× 1 — part
4.3 Teflon Tape shrink-wrap-machine-teflon-tape 2× 2 — part
4.4 Silicone Pad shrink-wrap-machine-silicone-pad 1× 1 — part
4.5 Coil Spring coil-spring 2× 2 — part
4.6 Seal Arm Lift 3 parts shrink-wrap-machine-arm-lift 1× 1 23 assembly
4.6.1 Stator Assembly 3 parts + deeper › stator-assembly 1× 1 3 assembly
4.6.2 Rotor Assembly 4 parts + deeper › rotor-assembly 1× 1 19 assembly
4.6.3 Coil Spring coil-spring 1× 1 — part
4.7 Sealing Transformer shrink-wrap-machine-seal-transformer 1× 1 — part
5 Shrink Tunnel 5 parts shrink-wrap-machine-shrink-tunnel 1× 1 82 assembly
5.1 Tunnel Chamber shrink-wrap-machine-tunnel-chamber 1× 1 — part
5.2 Heating Element heating-element 3× 3 — part
5.3 Circulation Blower 3 parts shrink-wrap-machine-circulation-blower 2× 2 23 assembly
5.3.1 Blower Motor blower-motor 1× 2 — part
5.3.2 Stator Assembly 3 parts + deeper › stator-assembly 1× 2 3 assembly
5.3.3 Rotor Assembly 4 parts + deeper › rotor-assembly 1× 2 19 assembly
5.4 Mesh Tunnel Conveyor 5 parts shrink-wrap-machine-tunnel-conveyor 1× 1 28 assembly
5.4.1 Mesh Conveyor Belt shrink-wrap-machine-mesh-belt 1× 1 — part
5.4.2 Stator Assembly 3 parts + deeper › stator-assembly 1× 1 3 assembly
5.4.3 Rotor Assembly 4 parts + deeper › rotor-assembly 1× 1 19 assembly
5.4.4 Drive Belt drive-belt 1× 1 — part
5.4.5 Ball Bearing ball-bearing 4× 4 — part
5.5 Air Baffle shrink-wrap-machine-air-baffle 4× 4 — part
6 Scrap Rewind 3 parts shrink-wrap-machine-scrap-rewind 1× 1 24 assembly
6.1 Stator Assembly 3 parts stator-assembly 1× 1 3 assembly
6.1.1 Stator Core (laminations) stator-core 1× 1 — part
6.1.2 Copper Winding copper-winding 1× 1 — part
6.1.3 Slot Insulation stator-insulation 1× 1 — part
6.2 Rotor Assembly 4 parts rotor-assembly 1× 1 19 assembly
6.2.1 Rotor Shaft rotor-shaft 1× 1 — part
6.2.2 Rotor Core rotor-core 1× 1 — part
6.2.3 Neodymium Magnet neodymium-magnet 16× 16 — part
6.2.4 Ball Bearing ball-bearing 1× 1 — part
6.3 Ball Bearing ball-bearing 2× 2 — part
7 Control Panel 4 parts shrink-wrap-machine-control-panel 1× 1 17 assembly
7.1 Control Board 5 parts shrink-wrap-machine-control-board 1× 1 13 assembly
7.1.1 Bare PCB pcb-bare 1× 1 — part
7.1.2 Microcontroller mcu 1× 1 — part
7.1.3 SMD Passive (R/C/L) smd-passives 1× 1 — part
7.1.4 Relay relay 4× 4 — part
7.1.5 Connector connector 6× 6 — part
7.2 LCD Panel lcd-panel 1× 1 — part
7.3 Touch Digitizer touch-digitizer 1× 1 — part
7.4 Thermocouple shrink-wrap-machine-thermocouple 2× 2 — part
8 Exhaust Hood 2 parts shrink-wrap-machine-exhaust 1× 1 2 assembly
8.1 Exhaust Duct shrink-wrap-machine-exhaust-duct 1× 1 — part
8.2 Blower Motor blower-motor 1× 1 — part
9 Machine Wiring 2 parts shrink-wrap-machine-wiring 1× 1 9 assembly
9.1 Wire Bundle wire-bundle 1× 1 — part
9.2 Connector connector 8× 8 — part
10 Fastener Set fastener-set 4× 4 — part

Sourcing — likely vendors

Companies that make this · indicative price $10k–$3M · MOQ & lead are typical
VendorHQSpecialtyMOQLead time
🇩🇪Heidelberg
heidelberg.com ↗ 		Heidelberg, DE Printing presses 10 units 12–22 wks
🇨🇭Bobst
bobst.com ↗ 		Lausanne, CH Packaging machinery 10 units 12–22 wks
🇩🇪Koenig & Bauer
koenig-bauer.com ↗ 		Würzburg, DE Printing presses 10 units 12–22 wks
🇩🇪Windmöller & Hölscher
wuh-group.com ↗ 		Lengerich, DE Flexible packaging machines 10 units 12–22 wks
🇺🇸Mark Andy
markandy.com ↗ 		Chesterfield, US Label presses 10 units 12–22 wks
