Industrial Steam Press Product
A commercial garment-finishing steam press: a padded lower buck and heated upper head close on a garment, injecting boiler steam through both surfaces and pulling vacuum through the buck to set and dry the fabric. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
12 top-level lines · 75 rows shown · 133 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Frame & Stand 5 parts | industrial-steam-press-frame | 1× | 1 | 8 | assembly |
| 1.1 | Base Weldment | industrial-steam-press-base-weldment | 1× | 1 | — | part |
| 1.2 | Head Pivot Bracket | industrial-steam-press-pivot-bracket | 1× | 1 | — | part |
| 1.3 | Cover Panel Set | industrial-steam-press-panel-set | 1× | 1 | — | part |
| 1.4 | Leveling Foot | industrial-steam-press-leveling-foot | 4× | 4 | — | part |
| 1.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Steam Buck 7 parts | industrial-steam-press-buck | 1× | 1 | 7 | assembly |
| 2.1 | Buck Form Shell | industrial-steam-press-buck-form | 1× | 1 | — | part |
| 2.2 | Buck Steam Chamber | industrial-steam-press-buck-chamber | 1× | 1 | — | part |
| 2.3 | Buck Perforation Plate | industrial-steam-press-buck-perforation | 1× | 1 | — | part |
| 2.4 | Heating Element | heating-element | 1× | 1 | — | part |
| 2.5 | Buck Padding | industrial-steam-press-padding | 1× | 1 | — | part |
| 2.6 | Buck Cover | industrial-steam-press-cover | 1× | 1 | — | part |
| 2.7 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3 | Steam Head 6 parts | industrial-steam-press-head | 1× | 1 | 6 | assembly |
| 3.1 | Head Platen | industrial-steam-press-head-platen | 1× | 1 | — | part |
| 3.2 | Head Steam Chamber | industrial-steam-press-head-chamber | 1× | 1 | — | part |
| 3.3 | Head Perforation Plate | industrial-steam-press-head-perforation | 1× | 1 | — | part |
| 3.4 | Heating Element | heating-element | 1× | 1 | — | part |
| 3.5 | Head Handle | industrial-steam-press-head-handle | 1× | 1 | — | part |
| 3.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 4 | Press Closure 5 parts | industrial-steam-press-closure | 1× | 1 | 9 | assembly |
| 4.1 | Pneumatic Cylinder 3 parts | industrial-steam-press-cylinder | 1× | 1 | 3 | assembly |
| 4.1.1 | Cylinder Tube | industrial-steam-press-cylinder-tube | 1× | 1 | — | part |
| 4.1.2 | Piston & Rod | industrial-steam-press-cylinder-piston | 1× | 1 | — | part |
| 4.1.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 4.2 | Toggle Linkage | industrial-steam-press-linkage | 1× | 1 | — | part |
| 4.3 | Coil Spring | coil-spring | 2× | 2 | — | part |
| 4.4 | Closure Air Valve | industrial-steam-press-air-valve | 1× | 1 | — | part |
| 4.5 | Linkage Pivot Pin | industrial-steam-press-pivot-pin | 2× | 2 | — | part |
| 5 | Steam Generator 8 parts | industrial-steam-press-boiler | 1× | 1 | 32 | assembly |
| 5.1 | Boiler Tank | industrial-steam-press-boiler-tank | 1× | 1 | — | part |
| 5.2 | Heating Element | heating-element | 2× | 2 | — | part |
| 5.3 | Water Feed Pump 4 parts | industrial-steam-press-feed-pump | 1× | 1 | 24 | assembly |
| 5.3.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 5.3.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 5.3.3 | Pump Fluid Head | industrial-steam-press-pump-head | 1× | 1 | — | part |
| 5.3.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5.4 | Pressure Switch | pressure-switch | 1× | 1 | — | part |
| 5.5 | Safety Relief Valve | industrial-steam-press-safety-valve | 1× | 1 | — | part |
| 5.6 | Thermal Fuse | thermal-fuse | 1× | 1 | — | part |
| 5.7 | Water Level Probe | industrial-steam-press-water-level-probe | 1× | 1 | — | part |
| 5.8 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6 | Steam Circuit 4 parts | industrial-steam-press-steam-circuit | 1× | 1 | 10 | assembly |
| 6.1 | Steam Solenoid Valve 3 parts | industrial-steam-press-steam-solenoid | 2× | 2 | 3 | assembly |
| 6.1.1 | Relay | relay | 1× | 2 | — | part |
| 6.1.2 | Steam Valve Body | industrial-steam-press-valve-body | 1× | 2 | — | part |
| 6.1.3 | O-Ring Set | oring-set | 1× | 2 | — | part |
| 6.2 | Steam Hose | industrial-steam-press-steam-hose | 2× | 2 | — | part |
| 6.3 | Steam Manifold | industrial-steam-press-steam-manifold | 1× | 1 | — | part |
| 6.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 7 | Vacuum System 4 parts | industrial-steam-press-vacuum | 1× | 1 | 25 | assembly |
| 7.1 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 7.2 | Vacuum Motor 2 parts | industrial-steam-press-vacuum-motor | 1× | 1 | 22 | assembly |
| 7.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 7.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 7.3 | Vacuum Damper Valve | industrial-steam-press-vacuum-valve | 1× | 1 | — | part |
| 7.4 | Vacuum Duct | industrial-steam-press-vacuum-duct | 1× | 1 | — | part |
| 8 | Foot Control 3 parts | industrial-steam-press-foot-control | 1× | 1 | 5 | assembly |
| 8.1 | Foot Pedal | industrial-steam-press-foot-pedal | 2× | 2 | — | part |
| 8.2 | Pedal Switch | industrial-steam-press-pedal-switch | 2× | 2 | — | part |
| 8.3 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 9 | Control System 5 parts | industrial-steam-press-control | 1× | 1 | 22 | assembly |
| 9.1 | Main Control Board 4 parts | industrial-steam-press-control-board | 1× | 1 | 16 | assembly |
| 9.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.1.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 9.1.3 | Relay | relay | 6× | 6 | — | part |
| 9.1.4 | Connector | connector | 8× | 8 | — | part |
| 9.2 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 9.3 | Thermostat | industrial-steam-press-thermostat | 2× | 2 | — | part |
| 9.4 | Thermocouple | industrial-steam-press-thermocouple | 2× | 2 | — | part |
| 9.5 | Timer Module | industrial-steam-press-timer | 1× | 1 | — | part |
| 10 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 11 | Connector | connector | 6× | 6 | — | part |
| 12 | Fastener Set | fastener-set | 2× | 2 | — | part |
