Video Intercom System Product
A building video door-entry system: a weatherproof outdoor door station with camera, keypad and RFID, two indoor touchscreen answering monitors, a power supply and bus distributor, an electric door release, surge protection and mounting hardware. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
8 top-level lines · 72 rows shown · 110 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Door Station 9 parts | intercom-system-door-station | 1× | 1 | 47 | assembly |
| 1.1 | Door Station Housing 5 parts | intercom-system-ds-housing | 1× | 1 | 5 | assembly |
| 1.1.1 | Faceplate | intercom-system-ds-faceplate | 1× | 1 | — | part |
| 1.1.2 | Flush Back Box | intercom-system-ds-backbox | 1× | 1 | — | part |
| 1.1.3 | Rain Hood | intercom-system-ds-rainhood | 1× | 1 | — | part |
| 1.1.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 1.1.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 1.2 | Entrance Camera Module 4 parts | intercom-system-ds-camera | 1× | 1 | 11 | assembly |
| 1.2.1 | Camera Module 3 parts + deeper › | camera-module | 1× | 1 | 3 | assembly |
| 1.2.2 | IR LED | intercom-system-ir-led | 6× | 6 | — | part |
| 1.2.3 | IR-Cut Filter | intercom-system-ir-cut-filter | 1× | 1 | — | part |
| 1.2.4 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.3 | Call Button & Keypad Panel 5 parts | intercom-system-call-panel | 1× | 1 | 12 | assembly |
| 1.3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.3.2 | Call Button | intercom-system-call-button | 8× | 8 | — | part |
| 1.3.3 | Keypad | intercom-system-keypad | 1× | 1 | — | part |
| 1.3.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 1.3.5 | Microcontroller | mcu | 1× | 1 | — | part |
| 1.4 | RFID Reader 4 parts | intercom-system-rfid-reader | 1× | 1 | 4 | assembly |
| 1.4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.4.2 | RFID Antenna Coil | intercom-system-rfid-antenna | 1× | 1 | — | part |
| 1.4.3 | RFID Reader IC | intercom-system-rfid-ic | 1× | 1 | — | part |
| 1.4.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 1.5 | Name Directory | intercom-system-name-directory | 1× | 1 | — | part |
| 1.6 | Microphone | intercom-system-microphone | 1× | 1 | — | part |
| 1.7 | Speaker | speaker | 1× | 1 | — | part |
| 1.8 | Door Station Main Board 5 parts | intercom-system-ds-mainboard | 1× | 1 | 8 | assembly |
| 1.8.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.8.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 1.8.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 1.8.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 1.8.5 | Connector | connector | 4× | 4 | — | part |
| 1.9 | Lock Relay Output 4 parts | intercom-system-lock-relay | 1× | 1 | 4 | assembly |
| 1.9.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 1.9.2 | Relay | relay | 1× | 1 | — | part |
| 1.9.3 | Flyback Diode | intercom-system-flyback-diode | 1× | 1 | — | part |
| 1.9.4 | Connector | connector | 1× | 1 | — | part |
| 2 | Indoor Monitor 7 parts | intercom-system-indoor-monitor | 2× | 2 | 18 | assembly |
| 2.1 | Touchscreen Display 4 parts | intercom-system-im-touchscreen | 1× | 2 | 4 | assembly |
| 2.1.1 | LCD Panel | lcd-panel | 1× | 2 | — | part |
| 2.1.2 | Touch Digitizer | touch-digitizer | 1× | 2 | — | part |
| 2.1.3 | LCD Backlight | intercom-system-im-backlight | 1× | 2 | — | part |
| 2.1.4 | Cover Glass | intercom-system-im-cover-glass | 1× | 2 | — | part |
| 2.2 | Indoor Monitor Main Board 5 parts | intercom-system-im-mainboard | 1× | 2 | 7 | assembly |
| 2.2.1 | Bare PCB | pcb-bare | 1× | 2 | — | part |
| 2.2.2 | Compute SoC Module | soc-module | 1× | 2 | — | part |
| 2.2.3 | Microcontroller | mcu | 1× | 2 | — | part |
| 2.2.4 | SMD Passive (R/C/L) | smd-passives | 1× | 2 | — | part |
| 2.2.5 | Connector | connector | 3× | 6 | — | part |
| 2.3 | Microphone | intercom-system-microphone | 1× | 2 | — | part |
| 2.4 | Speaker | speaker | 1× | 2 | — | part |
| 2.5 | Function Buttons | intercom-system-im-buttons | 1× | 2 | — | part |
| 2.6 | Monitor Housing 3 parts | intercom-system-im-housing | 1× | 2 | 3 | assembly |
| 2.6.1 | Front Bezel | intercom-system-im-front-cover | 1× | 2 | — | part |
| 2.6.2 | Rear Shell | intercom-system-im-rear-cover | 1× | 2 | — | part |
| 2.6.3 | Fastener Set | fastener-set | 1× | 2 | — | part |
| 2.7 | Wall Mount Bracket | intercom-system-wall-bracket | 1× | 2 | — | part |
| 3 | Power Supply | power-supply | 1× | 1 | — | part |
| 4 | Power & Bus Distributor 4 parts | intercom-system-power-distributor | 1× | 1 | 14 | assembly |
| 4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.2 | DIN-Rail Enclosure | intercom-system-din-enclosure | 1× | 1 | — | part |
| 4.3 | Branch Fuse | intercom-system-branch-fuse | 4× | 4 | — | part |
| 4.4 | Connector | connector | 8× | 8 | — | part |
| 5 | Bus / Network Wiring 2 parts | intercom-system-bus-wiring | 1× | 1 | 7 | assembly |
| 5.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 5.2 | Connector | connector | 6× | 6 | — | part |
| 6 | Electric Door Release 3 parts | intercom-system-door-release | 1× | 1 | 3 | assembly |
| 6.1 | Electric Strike | intercom-system-electric-strike | 1× | 1 | — | part |
| 6.2 | Strike Faceplate | intercom-system-strike-faceplate | 1× | 1 | — | part |
| 6.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 7 | Surge Protector | intercom-system-surge-protector | 1× | 1 | — | part |
| 8 | Fastener Set | fastener-set | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $50–$10k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| assaabloy.com ↗ | Stockholm, SE | Locks & access | 1,000 units | 8–12 wks |
| 🇺🇸Allegion allegion.com ↗ | Dublin, US | Security products (Schlage) | 1,000 units | 8–12 wks |
| dormakaba.com ↗ | Rümlang, CH | Access & door systems | 1,000 units | 8–12 wks |
| honeywell.com ↗ | Charlotte, US | Building & safety tech | 1,000 units | 8–12 wks |
| hikvision.com ↗ | Hangzhou, CN | Surveillance & security | 1,000 units | 8–12 wks |
