Motorized Blinds Product
A smart roller blind: an aluminium roller tube spun by an in-tube tubular motor, a Wi-Fi/BLE control board, a rechargeable Li-ion battery with optional solar top-up, the fabric shade itself, and an RF remote. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
9 top-level lines · 50 rows shown · 65 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Headrail Assembly 3 parts | motorized-blinds-headrail-assembly | 1× | 1 | 5 | assembly |
| 1.1 | Aluminium Roller Tube | motorized-blinds-roller-tube | 1× | 1 | — | part |
| 1.2 | End Cap | motorized-blinds-end-cap | 2× | 2 | — | part |
| 1.3 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2 | Tubular Motor 7 parts | motorized-blinds-tubular-motor | 1× | 1 | 29 | assembly |
| 2.1 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 2.1.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.1.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 2.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.2.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 2.2.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 2.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 2.2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 2.3 | Helical Gear Pair | gear-pair | 2× | 2 | — | part |
| 2.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.5 | Motor Casing | motorized-blinds-motor-tube | 1× | 1 | — | part |
| 2.6 | Drive Crown | motorized-blinds-crown | 1× | 1 | — | part |
| 2.7 | Drive Adapter | motorized-blinds-drive-adapter | 1× | 1 | — | part |
| 3 | Control Board 8 parts | motorized-blinds-control-board | 1× | 1 | 10 | assembly |
| 3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.4 | Motor Driver IC | motorized-blinds-motor-driver | 1× | 1 | — | part |
| 3.5 | Wireless Radio Module | motorized-blinds-radio-module | 1× | 1 | — | part |
| 3.6 | Antenna | motorized-blinds-antenna | 1× | 1 | — | part |
| 3.7 | Position Sensor | motorized-blinds-limit-sensor | 1× | 1 | — | part |
| 3.8 | Connector | connector | 3× | 3 | — | part |
| 4 | Battery Pack 4 parts | motorized-blinds-battery-pack | 1× | 1 | 7 | assembly |
| 4.1 | Li-ion Cell, 18650 | li-cell-18650 | 4× | 4 | — | part |
| 4.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 4.3 | Battery Housing | motorized-blinds-battery-housing | 1× | 1 | — | part |
| 4.4 | USB-C Charge Port | motorized-blinds-charge-port | 1× | 1 | — | part |
| 5 | Shade Assembly 2 parts | motorized-blinds-shade-assembly | 1× | 1 | 2 | assembly |
| 5.1 | Shade Fabric | motorized-blinds-fabric | 1× | 1 | — | part |
| 5.2 | Weighted Hem Bar | motorized-blinds-hem-bar | 1× | 1 | — | part |
| 6 | Bracket Set 2 parts | motorized-blinds-bracket-set | 1× | 1 | 3 | assembly |
| 6.1 | Mounting Bracket | motorized-blinds-bracket | 2× | 2 | — | part |
| 6.2 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 7 | RF Remote 5 parts | motorized-blinds-remote | 1× | 1 | 5 | assembly |
| 7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 7.3 | Button Keypad | motorized-blinds-remote-buttons | 1× | 1 | — | part |
| 7.4 | Remote Shell | motorized-blinds-remote-shell | 1× | 1 | — | part |
| 7.5 | CR2032 Coin Cell | motorized-blinds-coin-cell | 1× | 1 | — | part |
| 8 | Solar Charging Panel 3 parts | motorized-blinds-solar-panel | 1× | 1 | 3 | assembly |
| 8.1 | PV Cell | motorized-blinds-pv-cell | 1× | 1 | — | part |
| 8.2 | Solar Panel Housing | motorized-blinds-solar-housing | 1× | 1 | — | part |
| 8.3 | Connector | connector | 1× | 1 | — | part |
| 9 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
