Thermal Imaging Camera Product
A handheld thermal imager with a germanium IR lens, an uncooled microbolometer focal-plane array, a fused visible-light camera, and a colour LCD touchscreen. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
14 top-level lines · 64 rows shown · 389 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Housing Assembly 6 parts | thermal-camera-housing | 1× | 1 | 6 | assembly |
| 1.1 | Front Body Shell | thermal-camera-front-shell | 1× | 1 | — | part |
| 1.2 | Rear Body Shell | thermal-camera-rear-shell | 1× | 1 | — | part |
| 1.3 | Rubber Armour Overmould | thermal-camera-rubber-overmould | 1× | 1 | — | part |
| 1.4 | Hand Grip | thermal-camera-grip | 1× | 1 | — | part |
| 1.5 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 1.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Germanium Lens Assembly 4 parts | thermal-camera-lens-assembly | 1× | 1 | 7 | assembly |
| 2.1 | Germanium Lens Element | thermal-camera-ge-lens-element | 2× | 2 | — | part |
| 2.2 | AR-Coated Ge Window | thermal-camera-ar-coating-window | 1× | 1 | — | part |
| 2.3 | Lens Barrel | thermal-camera-lens-barrel | 1× | 1 | — | part |
| 2.4 | Focus Mechanism 3 parts | thermal-camera-focus-mechanism | 1× | 1 | 3 | assembly |
| 2.4.1 | Focus Stepper Motor | thermal-camera-focus-motor | 1× | 1 | — | part |
| 2.4.2 | Focus Cam Barrel | thermal-camera-focus-cam | 1× | 1 | — | part |
| 2.4.3 | Focus Control Ring | thermal-camera-focus-ring | 1× | 1 | — | part |
| 3 | Microbolometer Detector 6 parts | thermal-camera-detector | 1× | 1 | 6 | assembly |
| 3.1 | Microbolometer FPA Array | thermal-camera-fpa-array | 1× | 1 | — | part |
| 3.2 | ROIC | thermal-camera-roic | 1× | 1 | — | part |
| 3.3 | Thermoelectric Cooler (TEC) | thermal-camera-tec | 1× | 1 | — | part |
| 3.4 | NUC Shutter Flag | thermal-camera-shutter-flag | 1× | 1 | — | part |
| 3.5 | Shutter Flag Motor | thermal-camera-flag-motor | 1× | 1 | — | part |
| 3.6 | Detector Package Housing | thermal-camera-detector-housing | 1× | 1 | — | part |
| 4 | Sensor Front-End Board 5 parts | thermal-camera-front-end-board | 1× | 1 | 95 | assembly |
| 4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.2 | Detector Interface IC | thermal-camera-sensor-interface | 1× | 1 | — | part |
| 4.3 | Analog-to-Digital Converter | thermal-camera-adc | 1× | 1 | — | part |
| 4.4 | SMD Passive (R/C/L) | smd-passives | 90× | 90 | — | part |
| 4.5 | Connector | connector | 2× | 2 | — | part |
| 5 | Main Processor Board 7 parts | thermal-camera-main-board | 1× | 1 | 231 | assembly |
| 5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 5.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 5.4 | DDR RAM IC | thermal-camera-ram | 1× | 1 | — | part |
| 5.5 | NAND Flash IC | thermal-camera-flash | 1× | 1 | — | part |
| 5.6 | SMD Passive (R/C/L) | smd-passives | 220× | 220 | — | part |
| 5.7 | Connector | connector | 6× | 6 | — | part |
| 6 | Display Module 3 parts | thermal-camera-display | 1× | 1 | 3 | assembly |
| 6.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 6.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 6.3 | Display Bezel | thermal-camera-display-bezel | 1× | 1 | — | part |
| 7 | Visible-Light Camera 3 parts | thermal-camera-visible-cam | 1× | 1 | 3 | assembly |
| 7.1 | CMOS Image Sensor | thermal-camera-cmos-sensor | 1× | 1 | — | part |
| 7.2 | Visible Camera Lens | thermal-camera-vis-lens | 1× | 1 | — | part |
| 7.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8 | Laser Pointer Module 2 parts | thermal-camera-laser-pointer | 1× | 1 | 2 | assembly |
| 8.1 | Laser Diode | thermal-camera-laser-diode | 1× | 1 | — | part |
| 8.2 | Laser Collimator Optics | thermal-camera-laser-optics | 1× | 1 | — | part |
| 9 | Trigger & Button Cluster 4 parts | thermal-camera-trigger-buttons | 1× | 1 | 23 | assembly |
| 9.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.2 | Capture Trigger | thermal-camera-trigger | 1× | 1 | — | part |
| 9.3 | Navigation Button Set | thermal-camera-button-set | 1× | 1 | — | part |
| 9.4 | SMD Passive (R/C/L) | smd-passives | 20× | 20 | — | part |
| 10 | Battery Pack 3 parts | thermal-camera-battery | 1× | 1 | 3 | assembly |
| 10.1 | LiPo Cell | lipo-cell | 1× | 1 | — | part |
| 10.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 10.3 | Battery Door | thermal-camera-battery-door | 1× | 1 | — | part |
| 11 | Charge / Data Port 2 parts | thermal-camera-charge-port | 1× | 1 | 2 | assembly |
| 11.1 | Connector | connector | 1× | 1 | — | part |
| 11.2 | Port Sealing Flap | thermal-camera-port-flap | 1× | 1 | — | part |
| 12 | microSD Slot | thermal-camera-microsd-slot | 1× | 1 | — | part |
| 13 | Internal Wiring Harness 2 parts | thermal-camera-wiring | 1× | 1 | 6 | assembly |
| 13.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 13.2 | Connector | connector | 5× | 5 | — | part |
| 14 | Fastener Set | fastener-set | 1× | 1 | — | part |
