Endoscope System Product
A video endoscopy tower: a flexible video endoscope, video processor, light source, monitor, and cart. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 67 rows shown · 66 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Flexible Video Endoscope 6 parts | endoscope-system-scope | 1× | 1 | 24 | assembly |
| 1.1 | Insertion Tube 2 parts | endoscope-system-insertion-tube | 1× | 1 | 2 | assembly |
| 1.1.1 | Coil & Braid Layer | endoscope-system-spiral-coil | 1× | 1 | — | part |
| 1.1.2 | Outer Sheath | endoscope-system-outer-sheath | 1× | 1 | — | part |
| 1.2 | Distal Tip 5 parts | endoscope-system-distal-tip | 1× | 1 | 6 | assembly |
| 1.2.1 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 1.2.2 | Objective Lens Stack | endoscope-system-objective-lens | 1× | 1 | — | part |
| 1.2.3 | Distal Illumination | endoscope-system-led-illumination | 2× | 2 | — | part |
| 1.2.4 | Air/Water Nozzle | endoscope-system-airwater-nozzle | 1× | 1 | — | part |
| 1.2.5 | Tip Housing | endoscope-system-tip-housing | 1× | 1 | — | part |
| 1.3 | Bending Section 2 parts | endoscope-system-bending-section | 1× | 1 | 5 | assembly |
| 1.3.1 | Articulation Rings | endoscope-system-articulation-rings | 1× | 1 | — | part |
| 1.3.2 | Angulation Wire | endoscope-system-angulation-wires | 4× | 4 | — | part |
| 1.4 | Control Body 3 parts | endoscope-system-control-body | 1× | 1 | 5 | assembly |
| 1.4.1 | Angulation Knob | endoscope-system-angulation-knobs | 2× | 2 | — | part |
| 1.4.2 | Helical Gear Pair | gear-pair | 2× | 2 | — | part |
| 1.4.3 | Air/Water & Suction Valves | endoscope-system-control-valves | 1× | 1 | — | part |
| 1.5 | Umbilical Cord 2 parts | endoscope-system-umbilical | 1× | 1 | 4 | assembly |
| 1.5.1 | Light-Guide Connector | endoscope-system-light-guide-connector | 1× | 1 | — | part |
| 1.5.2 | Video Connector 3 parts + deeper › | endoscope-system-video-connector | 1× | 1 | 3 | assembly |
| 1.6 | Channel Set 2 parts | endoscope-system-channels | 1× | 1 | 2 | assembly |
| 1.6.1 | Working Channel | endoscope-system-working-channel | 1× | 1 | — | part |
| 1.6.2 | Air/Water Tubing | endoscope-system-airwater-tubing | 1× | 1 | — | part |
| 2 | Video Processor 4 parts | endoscope-system-processor | 1× | 1 | 16 | assembly |
| 2.1 | Image-Processing Board 5 parts | endoscope-system-processor-board | 1× | 1 | 8 | assembly |
| 2.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.1.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 2.1.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 2.1.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 2.1.5 | Connector | connector | 4× | 4 | — | part |
| 2.2 | Video Output Stage 3 parts | endoscope-system-video-output | 1× | 1 | 6 | assembly |
| 2.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.2.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 2.2.3 | Connector | connector | 4× | 4 | — | part |
| 2.3 | Power Supply | power-supply | 1× | 1 | — | part |
| 2.4 | Processor Chassis | endoscope-system-processor-chassis | 1× | 1 | — | part |
| 3 | Light Source 5 parts | endoscope-system-light-source | 1× | 1 | 7 | assembly |
| 3.1 | LED Lamp Module | endoscope-system-led-lamp | 1× | 1 | — | part |
| 3.2 | Reflector & Coupler | endoscope-system-light-coupler | 1× | 1 | — | part |
| 3.3 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 3.4 | Intensity Control Board 3 parts | endoscope-system-intensity-board | 1× | 1 | 3 | assembly |
| 3.4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.4.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.4.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.5 | Power Supply | power-supply | 1× | 1 | — | part |
| 4 | Surgical Monitor 4 parts | endoscope-system-monitor | 1× | 1 | 8 | assembly |
| 4.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 4.2 | Monitor Driver Board 3 parts | endoscope-system-monitor-board | 1× | 1 | 5 | assembly |
| 4.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.2.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 4.2.3 | Connector | connector | 3× | 3 | — | part |
| 4.3 | Monitor Arm | endoscope-system-monitor-arm | 1× | 1 | — | part |
| 4.4 | Power Supply | power-supply | 1× | 1 | — | part |
| 5 | Tower Cart 2 parts | endoscope-system-cart | 1× | 1 | 2 | assembly |
| 5.1 | Cart Frame | endoscope-system-cart-frame | 1× | 1 | — | part |
| 5.2 | Isolation Transformer | endoscope-system-isolation-transformer | 1× | 1 | — | part |
| 6 | Foot Pedal 3 parts | endoscope-system-footswitch | 1× | 1 | 4 | assembly |
| 6.1 | Pedal Switch | endoscope-system-foot-pedal-switch | 2× | 2 | — | part |
| 6.2 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.3 | Connector | connector | 1× | 1 | — | part |
| 7 | Water Bottle Unit 3 parts | endoscope-system-water-bottle | 1× | 1 | 5 | assembly |
| 7.1 | Water Bottle | endoscope-system-bottle | 1× | 1 | — | part |
| 7.2 | Irrigation Pump 3 parts | endoscope-system-water-pump | 1× | 1 | 3 | assembly |
| 7.2.1 | Pump Head | endoscope-system-pump-head | 1× | 1 | — | part |
| 7.2.2 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 7.2.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 7.3 | Irrigation Tubing | endoscope-system-irrigation-tubing | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $500–$3M · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| gehealthcare.com ↗ | Chicago, US | Medical imaging & devices | 100 units | 12–20 wks |
| siemens-healthineers.com ↗ | Erlangen, DE | Medical systems | 100 units | 12–20 wks |
| 🇳🇱Philips philips.com ↗ | Amsterdam, NL | Health technology | 100 units | 12–20 wks |
| medtronic.com ↗ | Minneapolis, US | Medical devices | 100 units | 12–20 wks |
| 🇨🇳Mindray mindray.com ↗ | Shenzhen, CN | Medical devices | 100 units | 12–20 wks |
