Hospital Bed Product
An electric ICU hospital bed with a four-section articulating deck, four linear actuators, integrated scale and CPR release. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
13 top-level lines · 66 rows shown · 186 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Base Frame 4 parts | hospital-bed-base-frame | 1× | 1 | 22 | assembly |
| 1.1 | Steel Base Chassis | hospital-bed-steel-base | 1× | 1 | — | part |
| 1.2 | Caster 3 parts | hospital-bed-caster | 4× | 4 | 4 | assembly |
| 1.2.1 | Caster Wheel | hospital-bed-caster-wheel | 1× | 4 | — | part |
| 1.2.2 | Ball Bearing | ball-bearing | 2× | 8 | — | part |
| 1.2.3 | Caster Brake Cam | hospital-bed-caster-brake | 1× | 4 | — | part |
| 1.3 | Corner Bumper | hospital-bed-bumper | 4× | 4 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Lift Mechanism 3 parts | hospital-bed-lift-mechanism | 1× | 1 | 4 | assembly |
| 2.1 | Lift Column | hospital-bed-lift-column | 2× | 2 | — | part |
| 2.2 | Scissor Linkage | hospital-bed-scissor-link | 1× | 1 | — | part |
| 2.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 3 | Mattress Platform 5 parts | hospital-bed-deck | 1× | 1 | 5 | assembly |
| 3.1 | Deck Frame | hospital-bed-deck-frame | 1× | 1 | — | part |
| 3.2 | Head/Back Section | hospital-bed-deck-head | 1× | 1 | — | part |
| 3.3 | Seat Section | hospital-bed-deck-seat | 1× | 1 | — | part |
| 3.4 | Thigh Section | hospital-bed-deck-thigh | 1× | 1 | — | part |
| 3.5 | Foot Section | hospital-bed-deck-foot | 1× | 1 | — | part |
| 4 | Linear Actuator 7 parts | hospital-bed-actuator | 4× | 4 | 27 | assembly |
| 4.1 | Stator Assembly 3 parts | stator-assembly | 1× | 4 | 3 | assembly |
| 4.1.1 | Stator Core (laminations) | stator-core | 1× | 4 | — | part |
| 4.1.2 | Copper Winding | copper-winding | 1× | 4 | — | part |
| 4.1.3 | Slot Insulation | stator-insulation | 1× | 4 | — | part |
| 4.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 4 | 19 | assembly |
| 4.2.1 | Rotor Shaft | rotor-shaft | 1× | 4 | — | part |
| 4.2.2 | Rotor Core | rotor-core | 1× | 4 | — | part |
| 4.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 64 | — | part |
| 4.2.4 | Ball Bearing | ball-bearing | 1× | 4 | — | part |
| 4.3 | Motor Housing | motor-housing | 1× | 4 | — | part |
| 4.4 | Helical Gear Pair | gear-pair | 1× | 4 | — | part |
| 4.5 | Ball Screw | ball-screw | 1× | 4 | — | part |
| 4.6 | Actuator Tube | hospital-bed-actuator-tube | 1× | 4 | — | part |
| 4.7 | Hall Sensor | hall-sensor | 1× | 4 | — | part |
| 5 | Control System 6 parts | hospital-bed-control-system | 1× | 1 | 18 | assembly |
| 5.1 | Control Box 3 parts | hospital-bed-control-box | 1× | 1 | 8 | assembly |
| 5.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.1.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 5.1.3 | Connector | connector | 6× | 6 | — | part |
| 5.2 | Hand Pendant 2 parts | hospital-bed-pendant | 1× | 1 | 2 | assembly |
| 5.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2.2 | Connector | connector | 1× | 1 | — | part |
| 5.3 | Nurse Control Panel | hospital-bed-nurse-panel | 1× | 1 | — | part |
| 5.4 | Power Supply | hospital-bed-power-supply | 1× | 1 | — | part |
| 5.5 | Battery Backup 2 parts | hospital-bed-battery-backup | 1× | 1 | 5 | assembly |
| 5.5.1 | LiPo Cell | lipo-cell | 4× | 4 | — | part |
| 5.5.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 5.6 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6 | Side Rail 2 parts | hospital-bed-side-rail | 4× | 4 | 3 | assembly |
| 6.1 | Rail Panel | hospital-bed-rail-panel | 1× | 4 | — | part |
| 6.2 | Rail Control Pad 2 parts | hospital-bed-rail-control | 1× | 4 | 2 | assembly |
| 6.2.1 | Bare PCB | pcb-bare | 1× | 4 | — | part |
| 6.2.2 | Connector | connector | 1× | 4 | — | part |
| 7 | Head Board | hospital-bed-head-board | 1× | 1 | — | part |
| 8 | Foot Board | hospital-bed-foot-board | 1× | 1 | — | part |
| 9 | CPR Release | hospital-bed-cpr-release | 1× | 1 | — | part |
| 10 | Bed Scale 2 parts | hospital-bed-scale | 1× | 1 | 10 | assembly |
| 10.1 | Load Cell | hospital-bed-load-cell | 4× | 4 | — | part |
| 10.2 | Scale Board 3 parts | hospital-bed-scale-pcb | 1× | 1 | 6 | assembly |
| 10.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 10.2.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 10.2.3 | Connector | connector | 4× | 4 | — | part |
| 11 | IV Pole | hospital-bed-iv-pole | 1× | 1 | — | part |
| 12 | Mattress 2 parts | hospital-bed-mattress | 1× | 1 | 2 | assembly |
| 12.1 | Foam Core | hospital-bed-mattress-foam | 1× | 1 | — | part |
| 12.2 | Mattress Cover | hospital-bed-mattress-cover | 1× | 1 | — | part |
| 13 | Accessory Kit | hospital-bed-accessory-kit | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $500–$3M · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| gehealthcare.com ↗ | Chicago, US | Medical imaging & devices | 100 units | 12–20 wks |
| siemens-healthineers.com ↗ | Erlangen, DE | Medical systems | 100 units | 12–20 wks |
| 🇳🇱Philips philips.com ↗ | Amsterdam, NL | Health technology | 100 units | 12–20 wks |
| medtronic.com ↗ | Minneapolis, US | Medical devices | 100 units | 12–20 wks |
| 🇨🇳Mindray mindray.com ↗ | Shenzhen, CN | Medical devices | 100 units | 12–20 wks |
