Autoclave Sterilizer Product
A benchtop steam autoclave: a heated reservoir boils water into the sealed stainless chamber while a radial-locking door, relief valve and interlock contain pressure through a vacuum-assisted sterilization cycle. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
11 top-level lines · 60 rows shown · 282 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Pressure Vessel & Door 6 parts | autoclave-vessel | 1× | 1 | 15 | assembly |
| 1.1 | Stainless Pressure Chamber | autoclave-chamber | 1× | 1 | — | part |
| 1.2 | Door Slab | autoclave-door | 1× | 1 | — | part |
| 1.3 | Radial Locking Mechanism 3 parts | autoclave-door-locking | 1× | 1 | 10 | assembly |
| 1.3.1 | Locking Ring | autoclave-locking-ring | 1× | 1 | — | part |
| 1.3.2 | Locking Lug | autoclave-locking-lug | 8× | 8 | — | part |
| 1.3.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 1.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 1.5 | Pressure Safety Interlock | autoclave-interlock | 1× | 1 | — | part |
| 1.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Heating System 4 parts | autoclave-heating | 1× | 1 | 5 | assembly |
| 2.1 | Heating Element | heating-element | 2× | 2 | — | part |
| 2.2 | Thermal Fuse | thermal-fuse | 1× | 1 | — | part |
| 2.3 | Water Reservoir | autoclave-reservoir | 1× | 1 | — | part |
| 2.4 | Water Level Sensor | autoclave-water-level-sensor | 1× | 1 | — | part |
| 3 | Steam & Plumbing Circuit 7 parts | autoclave-steam-plumbing | 1× | 1 | 29 | assembly |
| 3.1 | Fill / Drain Pump 3 parts | autoclave-fill-drain-pump | 1× | 1 | 23 | assembly |
| 3.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 3.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 3.1.3 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 3.2 | Fill Solenoid Valve | autoclave-fill-valve | 1× | 1 | — | part |
| 3.3 | Drain Valve | autoclave-drain-valve | 1× | 1 | — | part |
| 3.4 | Steam Trap | autoclave-steam-trap | 1× | 1 | — | part |
| 3.5 | Piping & Fittings | autoclave-piping | 1× | 1 | — | part |
| 3.6 | Inlet Water Filter | autoclave-water-filter | 1× | 1 | — | part |
| 3.7 | Sterile Air Filter | autoclave-air-filter | 1× | 1 | — | part |
| 4 | Pressure System 4 parts | autoclave-pressure-system | 1× | 1 | 26 | assembly |
| 4.1 | Pressure Switch | pressure-switch | 1× | 1 | — | part |
| 4.2 | Safety Relief Valve | autoclave-relief-valve | 1× | 1 | — | part |
| 4.3 | Vacuum Pump 3 parts | autoclave-vacuum-pump | 1× | 1 | 23 | assembly |
| 4.3.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 4.3.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 4.3.3 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 4.4 | Air Vent Valve | autoclave-air-vent | 1× | 1 | — | part |
| 5 | Control System 6 parts | autoclave-control | 1× | 1 | 191 | assembly |
| 5.1 | Main Controller Board 3 parts | autoclave-main-board | 1× | 1 | 162 | assembly |
| 5.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.1.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 5.1.3 | SMD Passive (R/C/L) | smd-passives | 160× | 160 | — | part |
| 5.2 | Relay | relay | 4× | 4 | — | part |
| 5.3 | Chamber RTD Probe | autoclave-rtd-probe | 2× | 2 | — | part |
| 5.4 | Drain Thermocouple | autoclave-thermocouple | 1× | 1 | — | part |
| 5.5 | Touchscreen Panel 4 parts | autoclave-touchscreen | 1× | 1 | 6 | assembly |
| 5.5.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 5.5.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 5.5.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.5.4 | Connector | connector | 3× | 3 | — | part |
| 5.6 | Connector | connector | 16× | 16 | — | part |
| 6 | Cycle Log Printer 3 parts | autoclave-printer | 1× | 1 | 4 | assembly |
| 6.1 | Thermal Print Head | autoclave-print-head | 1× | 1 | — | part |
| 6.2 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.3 | Connector | connector | 2× | 2 | — | part |
| 7 | Trays & Rack 3 parts | autoclave-loading | 1× | 1 | 5 | assembly |
| 7.1 | Loading Rack | autoclave-rack | 1× | 1 | — | part |
| 7.2 | Instrument Tray | autoclave-tray | 3× | 3 | — | part |
| 7.3 | Wire Basket | autoclave-basket | 1× | 1 | — | part |
| 8 | Chamber Jacket & Insulation | autoclave-jacket-insulation | 1× | 1 | — | part |
| 9 | Power Supply | power-supply | 1× | 1 | — | part |
| 10 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 11 | Leveling Foot | autoclave-foot | 4× | 4 | — | part |
