A compound trinocular laboratory microscope with Köhler LED illumination and a digital camera port. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 60 rows shown · 60 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Stand & Frame 4 parts | microscope-stand | 1× | 1 | 5 | assembly |
| 1.1 | Cast Base | microscope-cast-base | 1× | 1 | — | part |
| 1.2 | Support Arm | microscope-arm | 1× | 1 | — | part |
| 1.3 | Ergonomic Body Shell | microscope-body-shell | 1× | 1 | — | part |
| 1.4 | Fastener Set | fastener-set | 2× | 2 | — | part |
| 2 | Illumination System 4 parts | microscope-illumination | 1× | 1 | 6 | assembly |
| 2.1 | Lamp Module | microscope-lamp | 1× | 1 | — | part |
| 2.2 | Collector Lens | microscope-collector-lens | 1× | 1 | — | part |
| 2.3 | Field Diaphragm | microscope-field-diaphragm | 1× | 1 | — | part |
| 2.4 | Condenser Assembly 3 parts | microscope-condenser | 1× | 1 | 3 | assembly |
| 2.4.1 | Condenser Lens Group | microscope-condenser-lenses | 1× | 1 | — | part |
| 2.4.2 | Aperture Diaphragm | microscope-aperture-diaphragm | 1× | 1 | — | part |
| 2.4.3 | Condenser Height Adjuster | microscope-condenser-height | 1× | 1 | — | part |
| 3 | Mechanical Stage 4 parts | microscope-stage | 1× | 1 | 9 | assembly |
| 3.1 | Stage Plate | microscope-stage-plate | 1× | 1 | — | part |
| 3.2 | Specimen Clip | microscope-specimen-clips | 2× | 2 | — | part |
| 3.3 | Slide Holder | microscope-slide-holder | 1× | 1 | — | part |
| 3.4 | Coaxial XY Drive 4 parts | microscope-xy-drive | 1× | 1 | 5 | assembly |
| 3.4.1 | X-Axis Knob | microscope-x-knob | 1× | 1 | — | part |
| 3.4.2 | Y-Axis Knob | microscope-y-knob | 1× | 1 | — | part |
| 3.4.3 | Helical Gear Pair | gear-pair | 2× | 2 | — | part |
| 3.4.4 | Rack & Pinion | microscope-rack-pinion | 1× | 1 | — | part |
| 4 | Focus Mechanism 4 parts | microscope-focus | 1× | 1 | 7 | assembly |
| 4.1 | Coarse Focus Knob | microscope-coarse-knob | 1× | 1 | — | part |
| 4.2 | Fine Focus Knob | microscope-fine-knob | 1× | 1 | — | part |
| 4.3 | Focus Block 3 parts | microscope-focus-block | 1× | 1 | 4 | assembly |
| 4.3.1 | Dovetail Slide | microscope-dovetail-slide | 1× | 1 | — | part |
| 4.3.2 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 4.3.3 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 4.4 | Focus Tension Adjuster | microscope-tension-adjust | 1× | 1 | — | part |
| 5 | Revolving Nosepiece 2 parts | microscope-nosepiece | 1× | 1 | 11 | assembly |
| 5.1 | Turret Body | microscope-turret | 1× | 1 | — | part |
| 5.2 | Objective Lens 2 parts | microscope-objective | 5× | 5 | 2 | assembly |
| 5.2.1 | Objective Barrel | microscope-objective-barrel | 1× | 5 | — | part |
| 5.2.2 | Objective Lens Group | microscope-objective-lens-group | 1× | 5 | — | part |
| 6 | Trinocular Head 3 parts | microscope-head | 1× | 1 | 4 | assembly |
| 6.1 | Prism Assembly | microscope-prism | 1× | 1 | — | part |
| 6.2 | Eyepiece | microscope-eyepiece | 2× | 2 | — | part |
| 6.3 | Diopter Adjuster | microscope-diopter | 1× | 1 | — | part |
| 7 | Camera Port 7 parts | microscope-camera | 1× | 1 | 9 | assembly |
| 7.1 | C-Mount Adapter | microscope-c-mount | 1× | 1 | — | part |
| 7.2 | Camera Module 3 parts | camera-module | 1× | 1 | 3 | assembly |
| 7.2.1 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 7.2.2 | Lens Assembly | camera-lens | 1× | 1 | — | part |
| 7.2.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.3 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 7.4 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.5 | Microcontroller | mcu | 1× | 1 | — | part |
| 7.6 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 7.7 | Connector | connector | 1× | 1 | — | part |
| 8 | Digital Display 5 parts | microscope-display | 1× | 1 | 5 | assembly |
| 8.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 8.2 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 8.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 8.5 | Connector | connector | 1× | 1 | — | part |
| 9 | Power Supply 2 parts | microscope-power-supply | 1× | 1 | 2 | assembly |
| 9.1 | Power Supply Board | microscope-power-board | 1× | 1 | — | part |
| 9.2 | Connector | connector | 1× | 1 | — | part |
| 10 | Wire Bundle | wire-bundle | 2× | 2 | — | part |
