PCR Thermocycler Product
A real-time qPCR thermal cycler that drives 96 sample wells through programmed temperature cycles while reading fluorescence per cycle. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 50 rows shown · 384 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Housing & Heated Lid 5 parts | pcr-thermocycler-housing | 1× | 1 | 12 | assembly |
| 1.1 | Enclosure 2 parts | pcr-thermocycler-enclosure | 1× | 1 | 2 | assembly |
| 1.1.1 | Steel Chassis & Bezel | pcr-thermocycler-chassis | 1× | 1 | — | part |
| 1.1.2 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 1.2 | Heated Lid 3 parts | pcr-thermocycler-heated-lid | 1× | 1 | 3 | assembly |
| 1.2.1 | Heating Element | heating-element | 1× | 1 | — | part |
| 1.2.2 | Lid Temperature Sensor | pcr-thermocycler-lid-temp-sensor | 1× | 1 | — | part |
| 1.2.3 | Lid Platen | pcr-thermocycler-lid-platen | 1× | 1 | — | part |
| 1.3 | Lid Actuator 2 parts | pcr-thermocycler-lid-actuator | 1× | 1 | 2 | assembly |
| 1.3.1 | Lid Drive Motor | pcr-thermocycler-lid-motor | 1× | 1 | — | part |
| 1.3.2 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 1.4 | Rubber Foot | pcr-thermocycler-feet | 4× | 4 | — | part |
| 1.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Thermal Block 5 parts | pcr-thermocycler-thermal-block | 1× | 1 | 9 | assembly |
| 2.1 | 96-Well Sample Block | pcr-thermocycler-sample-block | 1× | 1 | — | part |
| 2.2 | Peltier Thermoelectric Module | peltier-module | 4× | 4 | — | part |
| 2.3 | Block RTD Sensor | pcr-thermocycler-block-rtd | 2× | 2 | — | part |
| 2.4 | Block Insulation | pcr-thermocycler-block-insulation | 1× | 1 | — | part |
| 2.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 3 | Heat Dissipation 2 parts | pcr-thermocycler-heat-dissipation | 1× | 1 | 2 | assembly |
| 3.1 | Heatsink | pcr-thermocycler-heatsink | 1× | 1 | — | part |
| 3.2 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 4 | Optical System 4 parts | pcr-thermocycler-optics | 1× | 1 | 14 | assembly |
| 4.1 | Excitation Module 2 parts | pcr-thermocycler-excitation | 1× | 1 | 5 | assembly |
| 4.1.1 | Excitation LED Array | pcr-thermocycler-led-array | 1× | 1 | — | part |
| 4.1.2 | Excitation Filter | pcr-thermocycler-excitation-filter | 4× | 4 | — | part |
| 4.2 | Emission Module 2 parts | pcr-thermocycler-emission | 1× | 1 | 5 | assembly |
| 4.2.1 | Emission Filter | pcr-thermocycler-emission-filter | 4× | 4 | — | part |
| 4.2.2 | Photodetector | pcr-thermocycler-detector | 1× | 1 | — | part |
| 4.3 | Optics Block | pcr-thermocycler-optics-block | 1× | 1 | — | part |
| 4.4 | Filter Wheel 2 parts | pcr-thermocycler-filter-wheel | 1× | 1 | 3 | assembly |
| 4.4.1 | Filter Wheel Motor | pcr-thermocycler-filter-motor | 1× | 1 | — | part |
| 4.4.2 | Excitation Filter | pcr-thermocycler-excitation-filter | 2× | 2 | — | part |
| 5 | Drive & Control Board 6 parts | pcr-thermocycler-control-board | 1× | 1 | 335 | assembly |
| 5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 5.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 5.4 | Peltier H-Bridge Driver | pcr-thermocycler-peltier-driver | 4× | 4 | — | part |
| 5.5 | SMD Passive (R/C/L) | smd-passives | 320× | 320 | — | part |
| 5.6 | Connector | connector | 8× | 8 | — | part |
| 6 | Touchscreen Display 3 parts | pcr-thermocycler-display | 1× | 1 | 3 | assembly |
| 6.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 6.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 6.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 7 | Power Supply | power-supply | 1× | 1 | — | part |
| 8 | I/O Panel 2 parts | pcr-thermocycler-io-panel | 1× | 1 | 4 | assembly |
| 8.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.2 | Connector | connector | 3× | 3 | — | part |
| 9 | 96-Well Sample Plate | pcr-thermocycler-sample-plate | 1× | 1 | — | part |
| 10 | Wire Bundle | wire-bundle | 3× | 3 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $1k–$500k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| thermofisher.com ↗ | Waltham, US | Lab instruments | 100 units | 10–18 wks |
| 🇺🇸Agilent agilent.com ↗ | Santa Clara, US | Analytical instruments | 100 units | 10–18 wks |
| 🇺🇸Bruker bruker.com ↗ | Billerica, US | Scientific instruments | 100 units | 10–18 wks |
| 🇯🇵Shimadzu shimadzu.com ↗ | Kyoto, JP | Analytical instruments | 100 units | 10–18 wks |
| 🇺🇸Waters waters.com ↗ | Milford, US | Chromatography & MS | 100 units | 10–18 wks |
