Tunnel Ventilation Fan Product

Overview

A tunnel ventilation fan is a large-capacity axial-flow or centrifugal blower mounted inside the tunnel that circulates air to remove dust, smoke, and hazardous gases generated during excavation and blasting. Tunnel ventilation is a critical safety system, particularly in underground construction where dust concentrations can reach health-hazard levels and methane or other explosive gases may accumulate.

Two main fan types are deployed:

1. Jet fans: small axial fans (0.8–1.5 m diameter) mounted high in the tunnel to push air longitudinally along the tunnel axis
2. Main extraction fans: large centrifugal or axial fans (1.5–2.5 m diameter) connected via ductwork that pull contaminated air toward the surface

Most tunneling operations use a combination: jet fans push fresh air from the portal toward the working face, while extraction fans pull contaminated air upward at the excavation zone.

Jet-Fan Design

The Fan Impeller Assembly is a fixed-pitch or variable-pitch axial rotor with 4–8 blades optimized for low pressure rise but high volume. Blade diameter is 0.8–1.5 m; rotation speed 1500–3000 rpm. Impeller Blade Set are aluminum airfoil sections that maintain high efficiency over a wide flow range.

The Electric Drive Motor is a direct-drive three-phase AC induction motor mounted coaxially. The entire unit (fan, motor, Fan Casing and Volute) is suspended from the tunnel crown via Tunnel Mounting System steel brackets with elastomer vibration isolators.

Performance Characteristics

Typical performance:

• Axial jet fan: 200–800 m³/s airflow; static pressure 50–150 Pa; power 100–300 kW
• Centrifugal main fan: 50–500 m³/s; static pressure 200–500 Pa; power 50–250 kW

Selection depends on tunnel cross-section, length, and ventilation strategy:

• Long tunnels (>2 km): multiple jet fans spaced 500–1000 m apart
• Short tunnels (<500 m): single main extraction fan + natural portal flow (no jet fans)
• Deep mines: combination of main extraction on downwind and boosters near the working face

Noise and Silencing

Tunnel ventilation fans generate 75–95 dB(A) noise—problematic for operator headsets and nearby surface communities. Inlet Silencer Unit and Outlet Silencer Unit reduce noise by 10–20 dB(A) through acoustic absorption (Acoustic Absorption Material) and expansion chambers (Acoustic Expansion Chamber).

Inlet silencers are preferred to outlet silencers because they don't add pressure loss to the suction side. Attenuation is proportional to silencer volume and absorption material thickness (typically 50–100 mm foam or fiberglass).

Variable-Speed Control

Modern tunnel-ventilation-fan-control-system use a Variable-Frequency Drive Cabinet (variable-frequency drive) to modulate fan speed based on:

• Dust concentration monitored by air-quality sensors at the face
• Gas detection (methane, CO, NO₂ levels)
• Manual operator demand via remote control

Speed reduction from 100% to 50% reduces power consumption to 12.5% (cube law) and noise to 84 dB(A) from 89 dB(A), providing significant energy and environment benefits during slow excavation or blasting delays.

The Fan Speed Sensor (tachometer or encoder) provides feedback to the tunnel-ventilation-fan-control-unit PLC, enabling closed-loop speed regulation.

Installation and Commissioning

Jet-fan installation in a 10 m wide tunnel:

1. Fabricate Mounting Bracket Frame steel structure with vibration isolators
2. Hoist fan assembly and bolt to brackets at 1.5–2.5 m height, 15–30° downward angle
3. Connect ductwork (if extracting) or deploy flex hose to inlet (if main fan)
4. Run Support and Guide Cables support cables (optional, for safety in seismic zones)
5. Commission VFD, test speed range, and verify airflow with anemometer traverse

Airflow verification requires point measurements across the tunnel cross-section; integrated volume must meet design specification (typically ±10% tolerance).

Maintenance Schedule

Weekly:

• Visual inspection for vibration, noise changes, temperature
• Check Pressure Transducer readings; report delta-P trends

Monthly:

• Bearing lubrication check and top-up (grease or oil-bath fans)
• Motor insulation resistance test (megohmmeter >5 MΩ minimum)
• Blade surface inspection for dust accumulation; light cleaning if airflow drops >5%

Annually:

• Bearing play check (axial and radial clearance); replace if >0.5 mm
• Motor winding thermal imager survey during load test
• VFD filter and capacitor inspection; fluid cooling check
• Acoustic attenuation retest; replace Acoustic Absorption Material if absorption <80% baseline

Every 5 years:

• Complete bearing pack replacement (even if play is acceptable)
• Impeller blade balance check; minor weight adjustment if needed
• Motor rewinding or replacement if carbon tracking observed in stator

Common Issues

Vibration and Noise:

• Loose blade fasteners or hub key
• Impeller imbalance (wear or erosion on one side)
• Bearing play >1 mm
• Soft vibration isolators (elastomer hardened or compressed)

Reduced Airflow:

• Blade fouling from dust accumulation
• Ductwork blockage (collapsed section or debris)
• Motor slip (capacitor bank failure in single-phase units; phase imbalance in three-phase)
• Bearing friction increase (lack of lubrication)

Motor Failures:

• High winding temperature (>150°C)
• Bearing noise (squealing = lubrication issue; grinding = bearing failure)
• Low insulation resistance (<1 MΩ) = moisture ingress or contamination

Most failures are preventable through consistent lubrication and vibration monitoring.
