Falling Film Evaporator Product
Vacuum evaporator with vertical calandria tubes, liquid distribution plate, and vapor separator concentrating dairy and food liquids at 10–100 kg/h throughput. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 33 rows shown · 27 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Vessel Body 4 parts | falling-film-evaporator-vessel-body | 1× | 1 | 5 | assembly |
| 1.1 | Shell | falling-film-evaporator-shell | 1× | 1 | — | part |
| 1.2 | Reinforcing Rings | falling-film-evaporator-reinforcing-rings | 1× | 1 | — | part |
| 1.3 | Inspection Port | falling-film-evaporator-inspection-port | 1× | 1 | — | part |
| 1.4 | Pressure Sensor | pressure-sensor | 2× | 2 | — | part |
| 2 | Calandria Bundle 5 parts | falling-film-evaporator-calandria-bundle | 1× | 1 | 5 | assembly |
| 2.1 | Tube Bundle | falling-film-evaporator-tube-bundle | 1× | 1 | — | part |
| 2.2 | Tube Sheet | falling-film-evaporator-tube-sheet | 1× | 1 | — | part |
| 2.3 | Steam Inlet | falling-film-evaporator-steam-inlet | 1× | 1 | — | part |
| 2.4 | Steam Outlet | falling-film-evaporator-steam-outlet | 1× | 1 | — | part |
| 2.5 | Flow Divider | falling-film-evaporator-flow-divider | 1× | 1 | — | part |
| 3 | Distribution Plate 3 parts | falling-film-evaporator-distribution-plate | 1× | 1 | 3 | assembly |
| 3.1 | Spray Nozzle | falling-film-evaporator-spray-nozzle | 1× | 1 | — | part |
| 3.2 | Splash Plate | falling-film-evaporator-splash-plate | 1× | 1 | — | part |
| 3.3 | Feed Conduit | falling-film-evaporator-feed-conduit | 1× | 1 | — | part |
| 4 | Vapor Separator 3 parts | falling-film-evaporator-vapor-separator | 1× | 1 | 3 | assembly |
| 4.1 | Cyclone Body | falling-film-evaporator-cyclone-body | 1× | 1 | — | part |
| 4.2 | Demister Pad | falling-film-evaporator-demister-pad | 1× | 1 | — | part |
| 4.3 | Separator Drain | falling-film-evaporator-separator-drain | 1× | 1 | — | part |
| 5 | Condenser 4 parts | falling-film-evaporator-condenser | 1× | 1 | 4 | assembly |
| 5.1 | Condenser Tubes | falling-film-evaporator-condenser-tubes | 1× | 1 | — | part |
| 5.2 | Cooling Pump | falling-film-evaporator-cooling-pump | 1× | 1 | — | part |
| 5.3 | Cooling Valve | falling-film-evaporator-cooling-valve | 1× | 1 | — | part |
| 5.4 | Condensate Outlet | falling-film-evaporator-condensate-outlet | 1× | 1 | — | part |
| 6 | Vacuum System 3 parts | falling-film-evaporator-vacuum-system | 1× | 1 | 3 | assembly |
| 6.1 | Vacuum Pump | falling-film-evaporator-vacuum-pump | 1× | 1 | — | part |
| 6.2 | Vacuum Valve | falling-film-evaporator-vacuum-valve | 1× | 1 | — | part |
| 6.3 | Vacuum Gauge | falling-film-evaporator-vacuum-gauge | 1× | 1 | — | part |
| 7 | Control Unit 4 parts | falling-film-evaporator-control-unit | 1× | 1 | 4 | assembly |
| 7.1 | Level Controller | falling-film-evaporator-level-controller | 1× | 1 | — | part |
| 7.2 | Feed Pump | falling-film-evaporator-feed-pump | 1× | 1 | — | part |
| 7.3 | Product Pump | falling-film-evaporator-product-pump | 1× | 1 | — | part |
| 7.4 | Control PLC | falling-film-evaporator-plc | 1× | 1 | — | part |
