Commercial Dishwasher Product
A door-type (hood) commercial warewasher: a single-rack pass-through machine with a recirculating wash tank, a fresh-water rinse fed by an electric booster heater, and chemical detergent/rinse-aid dosing. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
13 top-level lines · 109 rows shown · 211 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Cabinet & Frame 5 parts | commercial-dishwasher-cabinet | 1× | 1 | 9 | assembly |
| 1.1 | Welded Stainless Frame | commercial-dishwasher-frame | 1× | 1 | — | part |
| 1.2 | Stainless Side Panel | commercial-dishwasher-side-panel | 2× | 2 | — | part |
| 1.3 | Stainless Back Panel | commercial-dishwasher-back-panel | 1× | 1 | — | part |
| 1.4 | Adjustable Leg | commercial-dishwasher-leg | 4× | 4 | — | part |
| 1.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Lift Hood 6 parts | commercial-dishwasher-hood | 1× | 1 | 8 | assembly |
| 2.1 | Wash Hood Panel | commercial-dishwasher-hood-panel | 1× | 1 | — | part |
| 2.2 | Hood Handle | commercial-dishwasher-hood-handle | 1× | 1 | — | part |
| 2.3 | Counterbalance Spring | commercial-dishwasher-counterbalance-spring | 2× | 2 | — | part |
| 2.4 | Hood Guide Rail | commercial-dishwasher-hood-guide | 2× | 2 | — | part |
| 2.5 | Hood Interlock Switch | commercial-dishwasher-door-switch | 1× | 1 | — | part |
| 2.6 | Hood Gasket | commercial-dishwasher-hood-gasket | 1× | 1 | — | part |
| 3 | Wash Tank 8 parts | commercial-dishwasher-wash-tank | 1× | 1 | 9 | assembly |
| 3.1 | Tank Shell | commercial-dishwasher-tank-shell | 1× | 1 | — | part |
| 3.2 | Sump | commercial-dishwasher-sump | 1× | 1 | — | part |
| 3.3 | Scrap Screen Basket | commercial-dishwasher-scrap-screen | 1× | 1 | — | part |
| 3.4 | Strainer Pan | commercial-dishwasher-strainer-pan | 1× | 1 | — | part |
| 3.5 | Tank Immersion Heater 2 parts | commercial-dishwasher-tank-heater | 1× | 1 | 2 | assembly |
| 3.5.1 | Heating Element | heating-element | 1× | 1 | — | part |
| 3.5.2 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3.6 | Tank Thermostat | commercial-dishwasher-tank-thermostat | 1× | 1 | — | part |
| 3.7 | Thermal Fuse | thermal-fuse | 1× | 1 | — | part |
| 3.8 | Overflow Standpipe | commercial-dishwasher-overflow-tube | 1× | 1 | — | part |
| 4 | Wash Recirculation Pump 8 parts | commercial-dishwasher-wash-pump | 1× | 1 | 29 | assembly |
| 4.1 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 4.1.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 4.1.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 4.1.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 4.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 4.2.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 4.2.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 4.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 4.2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 4.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 4.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 4.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 4.6 | Pump Impeller | commercial-dishwasher-impeller | 1× | 1 | — | part |
| 4.7 | Pump Volute Housing | commercial-dishwasher-pump-volute | 1× | 1 | — | part |
| 4.8 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5 | Spray Arm System 5 parts | commercial-dishwasher-spray-system | 1× | 1 | 30 | assembly |
| 5.1 | Upper Wash Arm 2 parts | commercial-dishwasher-wash-arm-upper | 1× | 1 | 7 | assembly |
| 5.1.1 | Spray Arm Tube | commercial-dishwasher-arm-tube | 1× | 1 | — | part |
| 5.1.2 | Wash Jet Nozzle | commercial-dishwasher-wash-jet | 6× | 6 | — | part |
| 5.2 | Lower Wash Arm 2 parts | commercial-dishwasher-wash-arm-lower | 1× | 1 | 7 | assembly |
| 5.2.1 | Spray Arm Tube | commercial-dishwasher-arm-tube | 1× | 1 | — | part |
| 5.2.2 | Wash Jet Nozzle | commercial-dishwasher-wash-jet | 6× | 6 | — | part |
| 5.3 | Upper Rinse Arm 2 parts | commercial-dishwasher-rinse-arm-upper | 1× | 1 | 6 | assembly |
| 5.3.1 | Spray Arm Tube | commercial-dishwasher-arm-tube | 1× | 1 | — | part |
| 5.3.2 | Rinse Jet Nozzle | commercial-dishwasher-rinse-jet | 5× | 5 | — | part |
| 5.4 | Lower Rinse Arm 2 parts | commercial-dishwasher-rinse-arm-lower | 1× | 1 | 6 | assembly |
| 5.4.1 | Spray Arm Tube | commercial-dishwasher-arm-tube | 1× | 1 | — | part |
| 5.4.2 | Rinse Jet Nozzle | commercial-dishwasher-rinse-jet | 5× | 5 | — | part |
| 5.5 | Spray-Arm Pivot Bearing | commercial-dishwasher-arm-bearing | 4× | 4 | — | part |
| 6 | Rinse System 5 parts | commercial-dishwasher-rinse-system | 1× | 1 | 38 | assembly |
| 6.1 | Booster Heater 5 parts | commercial-dishwasher-booster | 1× | 1 | 6 | assembly |
| 6.1.1 | Booster Tank | commercial-dishwasher-booster-tank | 1× | 1 | — | part |
| 6.1.2 | Heating Element | heating-element | 2× | 2 | — | part |
| 6.1.3 | Booster Thermostat | commercial-dishwasher-booster-thermostat | 1× | 1 | — | part |
| 6.1.4 | Thermal Fuse | thermal-fuse | 1× | 1 | — | part |
| 6.1.5 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6.2 | Rinse Pressure Pump 6 parts | commercial-dishwasher-rinse-pump | 1× | 1 | 27 | assembly |
| 6.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 6.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 6.2.3 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 6.2.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 6.2.5 | Rinse Pump Impeller | commercial-dishwasher-rinse-pump-impeller | 1× | 1 | — | part |
| 6.2.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6.3 | Fill Solenoid Valve 3 parts | commercial-dishwasher-fill-valve | 1× | 1 | 3 | assembly |
| 6.3.1 | Relay | relay | 1× | 1 | — | part |
| 6.3.2 | Valve Body | commercial-dishwasher-valve-body | 1× | 1 | — | part |
| 6.3.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6.4 | Vacuum Breaker | commercial-dishwasher-vacuum-breaker | 1× | 1 | — | part |
| 6.5 | Rinse Supply Hose | commercial-dishwasher-rinse-hose | 1× | 1 | — | part |
| 7 | Chemical Dispenser System 4 parts | commercial-dishwasher-dispenser-system | 1× | 1 | 50 | assembly |
| 7.1 | Detergent Peristaltic Pump 3 parts | commercial-dishwasher-detergent-pump | 1× | 1 | 23 | assembly |
| 7.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 7.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 7.1.3 | Peristaltic Pump Head | commercial-dishwasher-peristaltic-head | 1× | 1 | — | part |
| 7.2 | Rinse-Aid Peristaltic Pump 3 parts | commercial-dishwasher-rinse-aid-pump | 1× | 1 | 23 | assembly |
| 7.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 7.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 7.2.3 | Peristaltic Pump Head | commercial-dishwasher-peristaltic-head | 1× | 1 | — | part |
| 7.3 | Chemical Dosing Tube | commercial-dishwasher-dosing-tube | 2× | 2 | — | part |
| 7.4 | Chemical Pickup Strainer | commercial-dishwasher-pickup-strainer | 2× | 2 | — | part |
| 8 | Drain Pump | drain-pump | 1× | 1 | — | part |
| 9 | Control System 3 parts | commercial-dishwasher-control | 1× | 1 | 23 | assembly |
| 9.1 | Main Control Board 4 parts | commercial-dishwasher-control-board | 1× | 1 | 18 | assembly |
| 9.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.1.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 9.1.3 | Relay | relay | 6× | 6 | — | part |
| 9.1.4 | Connector | connector | 10× | 10 | — | part |
| 9.2 | Touchscreen Panel 3 parts | commercial-dishwasher-touchscreen | 1× | 1 | 3 | assembly |
| 9.2.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 9.2.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 9.2.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.3 | Temperature Probe | commercial-dishwasher-temp-probe | 2× | 2 | — | part |
| 10 | Rack Set 3 parts | commercial-dishwasher-rack-set | 1× | 1 | 3 | assembly |
| 10.1 | Flat Plate Rack | commercial-dishwasher-flat-rack | 1× | 1 | — | part |
| 10.2 | Glass Rack | commercial-dishwasher-glass-rack | 1× | 1 | — | part |
| 10.3 | Cutlery Cylinder | commercial-dishwasher-cutlery-cylinder | 1× | 1 | — | part |
| 11 | Power & Water Connections 5 parts | commercial-dishwasher-utility-hookup | 1× | 1 | 8 | assembly |
| 11.1 | Power Terminal Block | commercial-dishwasher-terminal-block | 1× | 1 | — | part |
| 11.2 | Connector | connector | 4× | 4 | — | part |
| 11.3 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 11.4 | Water Inlet Fitting | commercial-dishwasher-water-inlet | 1× | 1 | — | part |
| 11.5 | Drain Outlet Fitting | commercial-dishwasher-drain-fitting | 1× | 1 | — | part |
| 12 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 13 | Fastener Set | fastener-set | 2× | 2 | — | part |
