A floor/bench commercial meat grinder: a geared induction motor drives an auger that forces meat through a knife and grinding plate. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
8 top-level lines · 49 rows shown · 108 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Body & Housing 4 parts | meat-grinder-body | 1× | 1 | 7 | assembly |
| 1.1 | Stainless Body Shell | meat-grinder-body-shell | 1× | 1 | — | part |
| 1.2 | Cast Base Plate | meat-grinder-base-plate | 1× | 1 | — | part |
| 1.3 | Rubber Foot | meat-grinder-foot | 4× | 4 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Induction Motor 6 parts | meat-grinder-motor | 1× | 1 | 27 | assembly |
| 2.1 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 2.1.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.1.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 2.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.2.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 2.2.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 2.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 2.2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 2.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 2.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.6 | Motor Cooling Fan | meat-grinder-cooling-fan | 1× | 1 | — | part |
| 3 | Reduction Gearbox 5 parts | meat-grinder-gearbox | 1× | 1 | 8 | assembly |
| 3.1 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 3.2 | Gearbox Housing | gearbox-housing | 1× | 1 | — | part |
| 3.3 | Ball Bearing | ball-bearing | 3× | 3 | — | part |
| 3.4 | Oil Seal | oil-seal | 2× | 2 | — | part |
| 3.5 | Food-Grade Gear Lubricant | meat-grinder-gear-lube | 1× | 1 | — | part |
| 4 | Grinding Head 9 parts | meat-grinder-head | 1× | 1 | 9 | assembly |
| 4.1 | Head Cylinder | meat-grinder-head-cylinder | 1× | 1 | — | part |
| 4.2 | Auger / Worm Screw | meat-grinder-auger | 1× | 1 | — | part |
| 4.3 | Cross Knife Blade | meat-grinder-knife | 1× | 1 | — | part |
| 4.4 | Grinding Plate (Coarse) | meat-grinder-plate-coarse | 1× | 1 | — | part |
| 4.5 | Grinding Plate (Fine) | meat-grinder-plate-fine | 1× | 1 | — | part |
| 4.6 | Ring Nut | meat-grinder-ring-nut | 1× | 1 | — | part |
| 4.7 | Feed Throat | meat-grinder-feed-throat | 1× | 1 | — | part |
| 4.8 | Feed Pan / Tray | meat-grinder-feed-pan | 1× | 1 | — | part |
| 4.9 | Pusher / Stomper | meat-grinder-pusher | 1× | 1 | — | part |
| 5 | Control Box 5 parts | meat-grinder-control-box | 1× | 1 | 50 | assembly |
| 5.1 | Forward/Reverse Switch | meat-grinder-switch | 1× | 1 | — | part |
| 5.2 | Control Board 2 parts | meat-grinder-control-pcb | 1× | 1 | 41 | assembly |
| 5.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2.2 | SMD Passive (R/C/L) | smd-passives | 40× | 40 | — | part |
| 5.3 | Thermal Overload Relay | meat-grinder-overload-relay | 1× | 1 | — | part |
| 5.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 5.5 | Connector | connector | 6× | 6 | — | part |
| 6 | Power Cord 3 parts | meat-grinder-power-cord | 1× | 1 | 4 | assembly |
| 6.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.2 | Connector | connector | 2× | 2 | — | part |
| 6.3 | Mains Plug | meat-grinder-plug | 1× | 1 | — | part |
| 7 | O-Ring Set | oring-set | 2× | 2 | — | part |
| 8 | Fastener Set | fastener-set | 1× | 1 | — | part |
