Commercial Dough Mixer Product
Floor-standing planetary commercial dough mixer: a cast-iron body houses an induction motor driving a reduction gearbox and planetary head that orbits interchangeable agitator tools (spiral hook, beater, whisk) inside a stainless steel bowl, with a microcontrolled speed/timer panel and a bowl-lift mechanism. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
8 top-level lines · 59 rows shown · 73 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Body & Frame 4 parts | cdm-body | 1× | 1 | 4 | assembly |
| 1.1 | Main Body Casting | cdm-body-casting | 1× | 1 | — | part |
| 1.2 | Floor Base | cdm-base | 1× | 1 | — | part |
| 1.3 | Head Casting | cdm-head | 1× | 1 | — | part |
| 1.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 2 | Induction Motor 6 parts | cdm-motor | 1× | 1 | 27 | assembly |
| 2.1 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 2.1.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.1.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 2.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.2.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 2.2.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 2.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 2.2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 2.3 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 2.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.6 | Motor Cooling Fan | cdm-motor-fan | 1× | 1 | — | part |
| 3 | Transmission 5 parts | cdm-transmission | 1× | 1 | 17 | assembly |
| 3.1 | Reduction Gearbox 5 parts | cdm-gearbox | 1× | 1 | 10 | assembly |
| 3.1.1 | Gearbox Housing | gearbox-housing | 1× | 1 | — | part |
| 3.1.2 | Helical Gear Pair | gear-pair | 2× | 2 | — | part |
| 3.1.3 | Ball Bearing | ball-bearing | 4× | 4 | — | part |
| 3.1.4 | Oil Seal | oil-seal | 2× | 2 | — | part |
| 3.1.5 | Gearbox Oil | cdm-gear-oil | 1× | 1 | — | part |
| 3.2 | Drive Belt | drive-belt | 1× | 1 | — | part |
| 3.3 | Pulley Set | cdm-pulley-set | 1× | 1 | — | part |
| 3.4 | Planetary Head 3 parts | cdm-planetary-head | 1× | 1 | 4 | assembly |
| 3.4.1 | Helical Gear Pair | gear-pair | 1× | 1 | — | part |
| 3.4.2 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 3.4.3 | Oil Seal | oil-seal | 1× | 1 | — | part |
| 3.5 | Agitator Output Shaft | cdm-agitator-shaft | 1× | 1 | — | part |
| 4 | Agitator Tool Set 4 parts | cdm-agitator-set | 1× | 1 | 4 | assembly |
| 4.1 | Spiral Hook | cdm-spiral-hook | 1× | 1 | — | part |
| 4.2 | Dough Hook | cdm-dough-hook | 1× | 1 | — | part |
| 4.3 | Flat Beater | cdm-flat-beater | 1× | 1 | — | part |
| 4.4 | Wire Whisk | cdm-whisk | 1× | 1 | — | part |
| 5 | Bowl Assembly 4 parts | cdm-bowl-assembly | 1× | 1 | 7 | assembly |
| 5.1 | Stainless Bowl | cdm-bowl | 1× | 1 | — | part |
| 5.2 | Bowl Guard | cdm-bowl-guard | 1× | 1 | — | part |
| 5.3 | Bowl Lift Mechanism 3 parts | cdm-bowl-lift | 1× | 1 | 3 | assembly |
| 5.3.1 | Lift Lever | cdm-lift-lever | 1× | 1 | — | part |
| 5.3.2 | Lift Screw | cdm-lift-screw | 1× | 1 | — | part |
| 5.3.3 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 5.4 | Bowl Clamp | cdm-bowl-clamp | 2× | 2 | — | part |
| 6 | Control Panel 8 parts | cdm-control-panel | 1× | 1 | 11 | assembly |
| 6.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 6.3 | Speed Selector | cdm-speed-selector | 1× | 1 | — | part |
| 6.4 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 6.5 | Relay | relay | 2× | 2 | — | part |
| 6.6 | Safety Interlock Switch | cdm-interlock-switch | 1× | 1 | — | part |
| 6.7 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.8 | Connector | connector | 3× | 3 | — | part |
| 7 | Power Cord 2 parts | cdm-power-cord | 1× | 1 | 2 | assembly |
| 7.1 | Mains Cord | cdm-cord | 1× | 1 | — | part |
| 7.2 | Connector | connector | 1× | 1 | — | part |
| 8 | Fastener Set | fastener-set | 1× | 1 | — | part |
