Milk Reception Unit Product
Integrated system for receiving raw or pasteurized milk with air elimination, flow metering, filtration, proportional sampling, and transfer pumping at 5000–50000 L/h. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 37 rows shown · 30 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Air Eliminator 5 parts | milk-reception-unit-air-eliminator | 1× | 1 | 5 | assembly |
| 1.1 | Vacuum Chamber | milk-reception-unit-vacuum-chamber | 1× | 1 | — | part |
| 1.2 | Separator Plate | milk-reception-unit-separator-plate | 1× | 1 | — | part |
| 1.3 | Vacuum Pump | milk-reception-unit-vacuum-pump | 1× | 1 | — | part |
| 1.4 | Vacuum Valve | milk-reception-unit-vacuum-valve | 1× | 1 | — | part |
| 1.5 | Pressure Sensor | pressure-sensor | 1× | 1 | — | part |
| 2 | Flow Meter 4 parts | milk-reception-unit-flow-meter | 1× | 1 | 4 | assembly |
| 2.1 | Meter Body | milk-reception-unit-meter-body | 1× | 1 | — | part |
| 2.2 | Meter Rotor | milk-reception-unit-meter-rotor | 1× | 1 | — | part |
| 2.3 | Meter Electronics | milk-reception-unit-meter-electronics | 1× | 1 | — | part |
| 2.4 | Meter Calibration | milk-reception-unit-meter-calibration | 1× | 1 | — | part |
| 3 | Filter Assembly 5 parts | milk-reception-unit-filter-assembly | 1× | 1 | 5 | assembly |
| 3.1 | Filter Body | milk-reception-unit-filter-body | 1× | 1 | — | part |
| 3.2 | Filter Screen | milk-reception-unit-filter-screen | 1× | 1 | — | part |
| 3.3 | Filter Drain | milk-reception-unit-filter-drain | 1× | 1 | — | part |
| 3.4 | Filter Bypass | milk-reception-unit-filter-bypass | 1× | 1 | — | part |
| 3.5 | Clogging Indicator | milk-reception-unit-clogging-indicator | 1× | 1 | — | part |
| 4 | Sampler Valve 4 parts | milk-reception-unit-sampler-valve | 1× | 1 | 4 | assembly |
| 4.1 | Sampler Body | milk-reception-unit-sampler-body | 1× | 1 | — | part |
| 4.2 | Sample Container | milk-reception-unit-sample-container | 1× | 1 | — | part |
| 4.3 | Solenoid Sampler | milk-reception-unit-solenoid-sampler | 1× | 1 | — | part |
| 4.4 | Sampler Strainer | milk-reception-unit-sampler-strainer | 1× | 1 | — | part |
| 5 | Transfer Pump 4 parts | milk-reception-unit-transfer-pump | 1× | 1 | 4 | assembly |
| 5.1 | Pump Motor | milk-reception-unit-pump-motor | 1× | 1 | — | part |
| 5.2 | Pump Unit | milk-reception-unit-pump-unit | 1× | 1 | — | part |
| 5.3 | Pump Check Valve | milk-reception-unit-pump-check-valve | 1× | 1 | — | part |
| 5.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6 | Control Unit 4 parts | milk-reception-unit-control-unit | 1× | 1 | 4 | assembly |
| 6.1 | Flow Controller | milk-reception-unit-flow-controller | 1× | 1 | — | part |
| 6.2 | Display Panel | milk-reception-unit-display-panel | 1× | 1 | — | part |
| 6.3 | Solenoid Valves | milk-reception-unit-solenoid-valves | 1× | 1 | — | part |
| 6.4 | Data Recorder | milk-reception-unit-data-recorder | 1× | 1 | — | part |
| 7 | Piping Manifold 4 parts | milk-reception-unit-piping-manifold | 1× | 1 | 4 | assembly |
| 7.1 | Manifold Block | milk-reception-unit-manifold-block | 1× | 1 | — | part |
| 7.2 | Isolation Valves | milk-reception-unit-isolation-valves | 1× | 1 | — | part |
| 7.3 | Check Valves | milk-reception-unit-check-valves | 1× | 1 | — | part |
| 7.4 | Drain Plug | milk-reception-unit-drain-plug | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $1k–$500k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| gea.com ↗ | Düsseldorf, DE | Process technology | 20 units | 12–20 wks |
| buhlergroup.com ↗ | Uzwil, CH | Food & materials processing | 20 units | 12–20 wks |
| tetrapak.com ↗ | Pully, CH | Food packaging & processing | 20 units | 12–20 wks |
| jbtc.com ↗ | Chicago, US | Food processing equipment | 20 units | 12–20 wks |
| alfalaval.com ↗ | Lund, SE | Heat transfer & separation | 20 units | 12–20 wks |
